Single & Twin Screw Filler Masterbatch Machine With Plastic Extruder Line
Single & Twin Screw Filler Masterbatch Machine With Plastic Extruder Line
GSmach Two-stage Extrusion
Usually the first compounding extruder runs at a high speed for good mixing and high output capacity. The second extruder must be a large diameter single screw one that can run at lower screw speed. The lower screw can avoid over - heating by internal cooling system and strong heat exchange ability. The functional separation allows operator to more flexibly control the expectable material mixing process and temperature.
Applicaton:
The two-stage Filler Masterbatch Machine applicable to products, PP,PE filler masterbatch, low smoke free halogen cable, PVC cable material, chemical crosslinking cable material, wood plastic, a wide range of uses.
Two-stage Filler Masterbatch Machine Model:
| Model | Main frame | Motor Power(kw) | Rotate Speed(rpm) |
| GSJ-50/100 | GS-50 twin screw extruder | 37-55 | 500-600 |
| GSD-100 single screw extruder | 22-45 | 60-90 | |
| GSJ-65/150 | GS-65 twin screw extruder | 55-75 | 500-600 |
| GSD-150 single screw extruder | 45-55 | 60-90 | |
| GSJ-75/180 | GS-75 twin screw extruder | 75-132 | 500-600 |
| GSD-180 single screw extruder | 75-90 | 60-90 | |
| GSJ-95/200 | GS-95 twin screw extruder | 250-315 | 400-500 |
| GSD-200 single screw extruder | 90-132 | 60-90 |
Machine Picture:
