+/- 0.03 mm Tolerance 3D Printer Filament Machine for 3D printing pla / abs
+/- 0.03 mm tolerance 3D Printer Filament Extruder machine for 3D printing pla / abs
General Introduction
About Safety operation rules of filament extruder machine: The grounding of electric equipment for machine tool must be good, two limit screws must be complete in the stroke block. During the operation of machine tools, it is forbidden to touch the handwheel at random, handle and electric button, to avoid an accident. It is forbidden to touch each moving part by hand. Tools and other objects are not allowed on the workbench. Grinding wheel protective cover for machine tool, belt protective cover and other safety devices must be intact and should not be dismantled at random. All fixed screws should be tightened.
Specifications
| Model | Power | Diameter | Capacity | Tolerance | Material |
| Lab machine | 200 W | 1.75-3 mm | 1-2 kg/h | +/- 0.05mm | PLA ABS HIPS PA PET |
| GSD-35 | 4 KW | 1.75-3 mm | 8-15 kg/h | +/- 0.03mm | PLA ABS HIPS PA PET |
| GSD-45 | 7.5 KW | 1.75-3 mm | 15-30 kg/h | +/- 0.03mm | PLA ABS HIPS PA PET |
| GSD-65 | 15 KW | 1.75-3 mm | 30-50 kg/h | +/- 0.03mm | PLA ABS HIPS PA PET |
Machine Composition
| Item | Equipment Line | QTY/SET |
| 1 | Mixer Machine | 1 |
| 2 | Vacuum Loader | 1 |
| 3 | Hopper Dryer | 1 |
| 4-1 | Single Screw Extruder | 1 |
| 4-2 | Die Head | 1 |
| 5 | Water Tank | 1 |
| 6 | Tractor Machine | 1 |
| 7 | Storage Thread Stand | 1 |
| 8 | Roundness Laser | 1 |
| 9 | Rolling Up Machine | 1 |
| 10 | Vacuum Packing | 1 |
Packing And Shipping
Plastic Filament Extruder for 3D Printers is packed in wooden cases.
