Industrial Centrifugal Slurry Pump Parts Rubber Cover Plate Liner
Slurry Pump Cover Plate Liner C2017 , Natural Rubber Pump Liners
Description:
Cover Plate Liner is the front rubber lined on a rubber lined slurry pump. For small pumps, the front liner is casted together with the throatbush, whereas for pumps like size 6/4 and bigger, the front cover liners will be separately casted from the throatbush. Thus, there are three parts that consist of the wetted parts for smaller pumps, but there are four for bigger pump models.
Modular design affords a high degree of interchangeability between metal and elastomer wear parts and mechanical components to simplify maintenance and to vary operating conditions.
Specifications:
| Natural Rubber | Standard |
| Hardness(Shore A) | 52±3 |
| 300% Stretching Strength(MPa) | ≥4 |
| Tensile Strength(MPa) | ≥21 |
| Elongation at Break(%) | ≥500 |
| Tensile Set at Break(%) | ≤25 |
| Rubber to Metal Bonding Pull Strength(MPa) | ≥5 |
| Akron Abrasion cm3/1.61km | ≤0.08 |
| Acid & Alkali Resistant PH Value(Liquid) |
3-12≤65℃ |
Explosive of Rubber Lined Slurry Pump:
SME orders of Rubber Pump Spare Parts:
Rubber Pump Application:
