Fly Ash Rubber Lined Slurry Pumps 60Kw Bare Shaft with 5 Vane Closed Impellers
Fly Ash Slurry Pump 60Kw Bare Shaft with 5 Vane Closed Impellers
Introduction:
SHR/100D is a 6/4D-R rubber pump with a max. capacity of 324 cubit meters and head up to 45m. The max. mating power is 60Kw, driven by electric motors and/or diesel engines.
Impeller:
The impeller may be either moulded elastomer or hard metal. Deep side sealing vanes relieve seal pressure and minimise recirculation. Cast-in impeller threads are better suited for slurries than impeller inserts or nuts.
Pump Base:
A one piece casting cradles the cartridge bearing assembly. A minimum number of through bolts hold the pump casing to the frame. A means of impeller adjustment is provided in a convenient position below the bearing housing.
Specifications:
| Model | SHR-100D |
| Outlet | 4-inch |
| Capacity | 144-324m3/h |
| TDH | 12-45m |
| Rated Power | 60Kw |
| Speed | 800-1350r/min |
| NPSH | 3-5m |
Construction of Slurry Pump:
Typical Applications:
Tailings
Heavy Mining
Ash Handling
Cyclone Feeds
Pulp and Paper
Corrosive Slurries
Coal Preparation
Mineral Processing
Aggregate Processing
Heavy Refusal Removal
Standard Material of Wet-end Parts: Natural Rubber
| Natural Rubber | Standard |
| Hardness(Shore A) | 52±3 |
| 300% Stretching Strength(MPa) | ≥4 |
| Tensile Strength(MPa) | ≥21 |
| Elongation at Break(%) | ≥500 |
| Tensile Set at Break(%) | ≤25 |
| Rubber to Metal Bonding Pull Strength(MPa) | ≥5 |
| Akron Abrasion cm3/1.61km | ≤0.08 |
| Acid & Alkali Resistant PH Value(Liquid) | 3-12≤65℃ |
Performance Curve:
