Hospital 140W Led Operation Theatre Lights 1300mm Illuminance Depth
Professional Surgery Light hospital operating room lamp led bulb
Product Descriptions:
All product models can be divided into focusing series and fixed focus series as well as custom series.
With the advancement of technology and the improvement of user requirements, only providing high-quality lighting effects can no longer meet the needs of users. Therefore, we have provided various customized orders for LED series shadowless lamps, including domestic round arms, imported round arms and imported square arms. Optional, also equipped with a high-quality video and camera system overall solution for users to choose, the camera includes built-in camera, external camera two.
Features:
1.With a super long LED life of 60, 000 hours, it is 40 times longer than halogen. At the same brightness, leds consume only a tenth of the energy of conventional incandescent bulbs and a half of halogen lamps.
2.The imported LED cold light has no infrared radiation, and the nano-coated radiator produces excellent heat dissipation effect. Use light-emitting diode as the light source, no temperature rise, no ultraviolet radiation, no stroboflash.
3.The perfect astral lamp effect, scientific radian focusing design, skillfully avoids the doctor's head and shoulder's shelter, achieves the ideal shadowless effect and the super deep lighting.
4.With imported high-performance lamp beads and efficient spatial layout, the energy saving effect under the same illumination is better than other international well-known brands.
5.To avoid the feeling of vertigo produced by surgeons, two kinds of lamp beads with similar color temperature were used.
6.The single 1W lamp bead produces relatively little heat.
7.Resistant to impact, recyclable waste and free of mercury pollution.
8.The electrically operated focusing adjustment mode. (optional)
Product Details:
| Type | 700500 (LED) Shadowless Operating lamp |
| Material | Aluminum Alloy |
| Illuminance(Lux) | 700 LED :>140,000 Lux; 500 LED :>120,000 Lux |
| Colour temperature(k) | 3800±500K,4400±500K,5000±500K |
| Colour rendering index(Ra) | 95 |
| Total irradiance (W/m2) | 450/390 |
| Size of light field (mm) | 160-280 |
| Illuminant Life | ≥50000h |
| Power supply voltage | AC110V-240V(50HZ-60HZ) |
| Total power consumption(W) | 140(80+60) |
| Total LED bulb quantity(pcs) | 180 pcs (18*6+12*6) |
| Lowest height of installation(mm) | 2900mm |
| Endo Mode | 3000k |
| Warranty | 2 years |
Packaging & Delivery
| 1 piece in a carton: | 91*92*37cm |
| GW/NW: | 19kg/12kg |
| 1 piece in a carton: | 81*80*36cm |
| GW:/NW: | 13.5kg/9kg |
| 1 piece in a wooden case: | 122*43*72cm |
| GW:/NW: | 65kg/50kg |
Installation Diagram
LED shadowless lamp is DC power, no strobe, it is not easy to make eye feeling fatigue, and the harmonic interference will not happened with other equipment in the work area.
1. Uniform illumination
Using a special optical system, 360 ° uniform illumination of the object being observed, no ghosting, highdefinition.
2. Energy saving and environmental protection
LED light has high luminous efficiency, impact resistance, not easily broken, no mercury pollution, and its light does not has radiation pollution.
