High Performance Split Case Fire Pump , Fire Fighting Water Pump 180kw Shaft Power
| Rated Flow | 2000 GPM |
| Rated Head | 128 PSI |
| Pump : NM Fire (UL/FM ) | SCF 250-200-500S (10x8”)) |
| Casing | Ductile Cast Iron |
| Impeller | SS304 |
| Shaft | AISI4340 |
| Shaft Sleeve | SS304 |
| Seal | Gland Packing |
| Wear Ring | Bronze |
| Bearing | SKF |
| Diesel Engine: NM FIRE (UL) | NM6-114 / 1760 rpm / 255HP |
| Control Panel: Tornatech (UL/FM) | GPD-24-120/220 |
| Motor: Techtop (UL) | TDC447T250U4B |
| Control Panel: Tornatech (UL/FM) | GPY series |
KEY FEATURES
- Single stage, medium pressure double inlet centrifugal pump with two flanged bearing frame, suitable for flexible
- coupling to electric motor or internal combustion engine as a driver;
- Ample dimensioned shaft guided through roller bearings and hardened shaft sleeve;
- Fully-enclosed single piece casting, double inlet impeller practically doesn’t produce any axial trust;
- High operating reliability due to maintenance and service parts;
- Spiral housing axially spitted means easy maintenance without pipe disconnection.
|
UL:
|
Q: 500-4000GPM | H:100-190PSI |
|
FM:
|
Q: 500-4000GPM | H:100-190PSI |
|
CCCF:
|
Q:20-500L/S | H:0.42-2.0Mpa |
|
NFPA20:
|
Q: 300-8000GPM | H:60-300PSI |
Application:
- Municipal water supply;
- Power plants;
- Industrial plants;
- Boiler feed and condensate systems;
- Irrigation and dewatering;
- General purposes.
