UL Listed / FM Approved Diesel Engine Driven Pump Split Case 1250gpm@ 95m Head

Pump: Split case Pump
Model: SCF200-125-300(UL/FM)
Q= 1250usgpm H=95m n=2980
rpm(1500gpm@91m)
Material:
Casing---Ductile Cast iron
Impeller---SS304
Shaft--- AISI 4340
Shaft sleeve---SS304
Seal------ Gland packing
Wear ring----Bronze
Bearing---SKF

Engine: Demaas(FM)
Model: IF05ATIH-F
132kw at 2940rp

Controller : Eaton (UL/FM)
Model: FD120-L1

The Split Case Fire Pump is designed to provide water to stand pipe, sprinkler, chemical mitigation and hydrant systems for fire supression in industrial and commercial facilities.
Features and Benefits:
Available in capacities up to 7000 GPM
Pressures up to 315 PSI
In compliance with NFPA #20, UL or FM
Performance and hydrostatic tests.
Dynamic balance impellers.
Space saving design.
Easy maintenance and upkeep.
Available in electric or diesel engine driven models.
