High Pressure Red Electric Motor Driven Fire Pump NFPA 20 UL FM 284M3/H 2313 PSI
Price:
Negotiation
MOQ:
1set
Delivery Time:
60 Days
Brand:
CNP NM FIRE
Product Description
-
Electic Motor Driven split case centrifugal pum 1250GPM 220m Techtop Motor NFPA20 Fire Fighting Pump
-
Split Case Motor Pump SetProduct Details
| Diesel Engine Pump Set( Heat Exchanger) | ||
| NM Fire Split Case Pump | ||
| Model | SCF200-150-420 | This Diesel Engine Group includes the pump(air relieve vlave , inlet & outlet gauges) Diesel Engine, Commonbase, Flexible exhaust connector, Control System, Battery, Silencer, Coupling (non-listed), Cooling System. Please contact me if you need Fuel tank, Main relief valve,Waste corn or other accessories. |
| Capacity | 284M3/H | |
| Head | 313PSI | |
| RPM | 1800rpm | |
| Material: | ||
| Casing | Ductile Cast iron | |
| Impeller | SS304 | |
| Shaft | AISI 4340 | |
| Shaft sleeve | SS304 | |
| Seal | Gland packing | |
| Wear ring | Bronze | |
| Bearing | SKF | |
| Engine: NM&UL | ||
| Model: | NM6-128 | |
| 457HP at 1760rpm | ||
| Controller : Tornatech (UL/FM) | ||
| Model: | GPD-24-220/240 | |
![]()
Standards
NFPA20, UL, FM, EN12845,CCCF Performance Ranges UL : Q: 100-750GPM H:70-152PSI FM: Q: 100-750GPM H:70-152PSI CCCF: Q:15-45L/S H:0.6-0.9Mpa NFPA20: Q: 100-3000GPM H:40-200PSI
-
Application:
Large hotels, hospitals , schools,office buildings,supermarkets, commercial residential buildings, metro stations, railway stations, airports, kinds of transportation tunnels, petrochemical plants, thermal power plants, terminals, oil depots, large warehouses and industrial and mining enterprises, etc.
-
Five Advantages of CNP NM FIRE
①The late-mover advantage of products, we R&D better fire products than other Suppliers; ②Have the most complete and all series of fire pump models; ③Have listed diesel engines with self-owned brand--- NM FIRE; ④Understand the technology of fire- fighting products and fire- fighting system better than other competitors and have better services; ⑤Shorter delivery time.
Please contact us if you have any other requirements.
Thanks
Diesel Testing bench
UL or NFPA 20 Compliant-non-approved
Power Range:30-2000HP
Speed Range:1450-3000RPM
-
FAQ
Q1.Do you have the UL-LISTED Fire Pump Sets? Yes, We have the UL/FM and NFPA standard Fire Pump Sets. Q2.I need your motor drive End-suction/Split-casing fire pump, what information shold I sent to you ? Sir/Madam,you can privide the Capacity, Heed, Voltage and Frequncy,we will make the quotation for you,If you need Jockey Pump or other accessories, please tell us together. Q3.If I need your Diesel Engine Drive End-suction/Split-casing fire pump, what information shold I sent to you ? You can sent the Capacity Heed, Temperature and Altitude (temperature and altitude will affect the performance of diesel engines).If you need Jockey Pump or other accessories, please tell us Voltage and Frequncy or accessories together. Q4.I need the UL/FM Vertical Tubine Fire Pump Set ,please sent me the price. For the motor Diver Vertical Tubine Fire Pump Set: you shoul give us the Capacity, Heed, Voltage Frequncy and the tank deep. For the Diesel Engine Drive Vertical Tubine Fire Pump Set:you should give us the Capacity, Heed and the tank deep. If you need Jockey Pump or other accessories,please tell us together.
-
Service:
1. Reply within 24 hours.
2. High-quality products and the most reasonable price
3. Data and chemical technology support.
