Cordierite Refractory Kiln Tray Thermal Shock Resistance High Strength 1250℃
Excellent thermal shock resistance Cordierite refractory kiln tray
1. Description
A saggar is a type of kiln furniture. It is a ceramic boxlike container used in the firing of pottery to enclose or protect ware being fired inside a kiln. Traditionally, saggars were made primarily from fireclay.Saggars have been used to protect, or safeguard, ware from open flame, smoke, gases and kiln debris: the name is a contraction of the word safeguard.
Cordierite kiln tray is also called cordierite sagger .it is widely used for sinter powder and ceramic.
it has the advantages of cordierite.It is very strong in high temperature furnace,max working temperature 1250℃.
The advanced processing equipment and the production craft coupled with excellent inspecting instrument and strict production craft have ensured the good quality of our product. Meanwhile, the unceasing technical investment and the talented specialized technically personnel have been keeping the manufacturing technology always in the lead.
2. Deatails For Refractory kiln tray
| property | cordierite | mullite | cordierite- mullite | Mullite -- corundum | |
| Al2O3 % | ≥ 40 | ≥ 65 | ≥ 80 | ≥ 92 | |
| Fe2O3 % | ≤ 1.5 | ≤ 1.5 | ≤ 1.2 | ≤ 0.5 | |
| density g/cm3 | ≥2.0 | ≥2.4 | ≥2.6 | ≥3.7 | |
| Thermal expansion 1000 C | 2.30 | 5.0 | 6.50 | 7.8 | |
| Refractoriness C | ≥ 1580 | ≥1650 | ≥ 1750 | ≥ 1850 | |
| Thermal stability 1100 C--(cold water)times | ≥ 70 | ≥ 20 | ≥ 10 | ≥ 5 | |
| Working temperature | ≤ 1250 | ≤ 1350 | ≤ 1450 |
≤ 1500 |
|
3. Our Advantage
1. We will supply with the best price in 24 hours.
2. We will supply with all information to u ,about package, weight,
3. High Presion per special request
4. We can communicate with u by Fluently and professional English .
5. For all products u buy, Our product's warranty is for 2 years. For product problem, u can contact with us any time.
