Metal Coil Architectural Woven Metal Mesh Fabric Drapery Curtains
Metal Coil Drapery Architectural Metal Mesh Fabric Drapery Curtains
Specifications
Metal mesh fabric drapery curtain
1.Material:Aluminum alloy,stainless steel,steel...
2.Feature:fadeless
Introduction of Metal coil drapery architectural metal mesh fabric drapery curtains :
1).Material: stainless steel wire 304 316 316l, copper wire, Aluminum wire etc.
2).Wire diameter: 0.6-1.2mm all are available (can be customized)
3).Aperture: 4*4mm-35mm*35mm
4).Mesh length: can reach 20m
5).Mesh width: According to custom requirment.
pecification table of Metal coil drapery architectural metal mesh fabric drapery curtain :
|
Metal Drapery Specification
|
||||
| Material | Wire dia (mm) |
Aperture (mm) |
Theoratical Weight (kg/m2) | Surface Treatment |
| AISI 304/316 | 1 | 5 | 3.3 | Natural polished |
| 1 | 8.4 | 3.5 | ||
| 1.2 | 6.8 | 5.8 | ||
| Al-Mg Alloy | 1.2 | 4 | 1.9 | Paint-spray /Anodizing |
| 1.2 | 5 | 1.5 | ||
| 1.2 | 6 | 1.25 | ||
| 1.2 | 7 | 1.13 | ||
| 1.2 | 8 | 1.2 | ||
| 1.2 | 9 | 0.85 | ||
| Aluminum | 1 | 5.5 | 1.5 | |
| 1.2 | 6.8 | 2.5 | ||
| 1.2 | 8.5 | 2 | ||
| Carbon Steel | 0.9 | 6.3 | 4 | |
| 1 | 6.8 | 5.5 | ||
| 1.2 | 8.5 | 6 |
||
Feature of Metal coil drapery architectural metal mesh fabric drapery curtain : Acid-resisting, alkalinity-resisting, heat-resisting, wear-resisting and oxidize-resisting.
