Automatic Salt Spray Corrosion Test Chamber 40/60/90/120 Metal Plating Salt Spray Test Machine
Automatic Salt Spray Corrosion Test Chamber 40/60/90/120 Salt Spray Test Machine Metal Plating Salt Spray Test Machine
Product introduction:
Salt spray corrosion test chamber by evaluating the salt spray corrosion ability of the material and its protective layer, and comparing with the process quality of the similar protective layer, the surface treatment of a variety of materials, including coating, electroplating, organic and inorganic skin film, anodic treatment, anti-rust oil and other anti-corrosion treatment, to test the corrosion resistance of its products. At the same time, the salt spray corrosion resistance of some products can be evaluated. This product is suitable for salt spray corrosion test of parts, electronic components, metal material protection layer and industrial products.
Application Industry:
Salt spray chamber is mainly artificial simulation of corrosion standard environment, used to test long-term corrosive environment in the material or surface coating corrosion resistance.Salt spray test chamber widely used in hardware, electroplating, electronics, chemicals, automotive, aviation, coatings, wire and cable, circuit boards, communications and other industries.
Chamber Structure:
1. Salt spray test machine cover is made of transparent materials so that the operator can see the tested sample in the chamber and the spraying situation of the tested sample .
2. A waterproof structure is adopted between the chamber cover and chamber body and thus there is no salt spray overflow .
3. Adopts the tower spraying system and equipped with the salt solution filter system and non-crystal nozzle so as to realize even salt spray distribution and freely adjustable settlement .
Main technical parameters :
| Model | YY1015-60 | YY1015-90 | YY1015-120 |
| Inner box size: ( L×W×H ) cm | 60×40×45 | 90×60×50 | 120×100×50 |
| Outside box size: ( L×W×H ) cm | 107×60×118 | 141×88×128 | 190×130×140 |
| Equipment material: | P.V.C & P.P | ||
| Temperature range: | 35°C~55°C | ||
| Temperature fluctuations: | ≤±0 . 5°C | ||
| Temperature uniformity: | ≤±2°C | ||
| Temperature precision: | ±1°C | ||
| Test chamber temperature: | NSS ACSS 35±1°C CASS : 50±1°C | ||
| Saturated air barrel temperature: | NSS ACSS 47±1°C CASS 63±1°C | ||
| Brine temperature: | 35°C±1°C | ||
| Spray quantity: | 1 . 0~2 . 0 ml / 80cm2 / hr | ||
| PH: | NSS ACSS6 . 5~7 . 2 CASS 3 . 0~3 . 2 | ||
| Lab volume: | 108L | 270L | 600L |
| Brine tank capacity: | 15L | 25L | 40L |
| Power: | 1AC220V , 10A | 1AC220V , 15A | AC 1 , 220V , 30A |
| Safety Devices: | Overheating prevention circult-breaker,dehydration and overheating prevention mechanism,breakdown indicator light |
||
| Standard accessories: | Test salt, measure bucket, tool etc 1 set | ||
Specifications:
Salt Spray Test Chamber
1. Durable hard PVC construction
2. Anti-corrosion ,
3. Easy clean & operate
4. 1 year warranty
Features :
1. Provides USB Host for USB flash drive
2. Touch-screen operator control interface.
3. ‘Easy Open’ pneumatically operated canopy.
4. Dry seal gasket prevents wetting operator’s clothes, etc.
5. Low loading threshold for loading and unloading.
6. Large capacity floor standing salt solution reservoir.
7. Calibration certificate.
8. Canopy color choice.
9. Set of sample racks.
Salt Spray Test Chamber Material:
2) Laboratory closure with high impact acrylic sheet, 6 mm thick;
3) Supplementary bottles of reagents attached to the water level perspective with hidden windows, clean easy, not easy to break;
4) Saturated air barrel using SUS #304 stainless steel barrel high pressure barrel insulation is best;
5) Laboratory basketball adopt flat indexing frame, adjustable angle, surrounded by mist side down exactly the same place the large number of test pieces.
