ASTM D2256 Electronic Single Yarn Strength Tester, ISO2062 Textile Testing Equipment

Description:

Electronic Single Yarn Strength Tester is suitable for determining the breaking load and extension of single yarns. It does adopt CRE principle and automatically operated with pneumatic/magnetic clamp, provided with scales 0-5000cN force max.

Standards:

GB/T14344, GB/T3916, ISO2062, ASTM D2256

Parameters:

1. Force scale:0-1000cN; 0-3000cN; 0-5000cN

2. Force division: 0.5CN; 1CN; 1cN

3. Precision:<=1 %F.S

4. Extension speed:50-1000mm/min (adjustable)

5. Reverting speed:50-1000mm/min (adjustable)

6. Extension scale:100mm,250mm,500mm (three selection)

7. Pretension: 0～150cN (adjustable)

8. Power:AC 220V±10% 50Hz

9. Dimension: 370*450*970mm

10. Weight:60kg
