27T Huge Capacity Foam Fire Truck Six Seats With 100W Alarm Control System
Price:
Negotiable
MOQ:
1 unit
Delivery Time:
90 days after sign contract
Brand:
Jindun
Product Description
27T Huge Capacity Foam Fire Truck Six Seats With 100W Alarm Control System
Vehicle
| Dimension (L×W×H) | 9920×2500×3600mm |
| Gross weight | 27550kg |
| Complete vehicle shipping mass | 14900kg |
| Seat (inc. driver) | 6 |
| Max. power | 276kw |
Chassis for industrial foam fire truck
| Manufacturer | Sinotruk HOWO |
| Model | ZZ5347V4347D5 |
| Drive type | 6x4 |
| Cab | Flattop metal forward turnover |
| Wheelbase | 4325+1350mm |
| Max. speed | 90km/h |
| Min. turning diameter | <22m |
| Approach angle | 16° |
| Departure angle | 12° |
| Engine type | In-line six-cylinder, water inter-cooling, direct injection diesel engine |
| Model | D10.38—40 |
| Max. power | 276kw |
| Max. torque | 1560N•m |
| Emission standard | China IV |
| Clutch | Pull, dry |
| Gearbox model | Manual, 9 forward gear |
| Tyre | 12.00R20/10 |
Electrical system
The main lights in the cab at the top of the long row of lights, configure the 100W alarm control system; a strobe lights installed on both sides and the middle of each compartment (two red and blue)
Onboard document
- Vehicle operation and maintenance manual
- Chassis operating manual
- Chassis operation and maintenance manual
- Chassis quality warranty card
- Chassis certificate, vehicle certificate, 3C logo
- Engine code copy
- Chassis code copy
- Onboard equipment list
- Follow-up service card
- Hand-over list
