6x4 Drive Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg
6x4 Drive Type Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg
Vehicle
| Dimension (L×W×H) | 9920×2500×3600mm |
| Gross weight | 27550kg |
| Complete vehicle shipping mass | 14900kg |
| Seat (inc. driver) | 6 |
| Max. power | 276kw |
Chassis
| Manufacturer | Sinotruk HOWO |
| Model | ZZ5347V4347D5 |
| Drive type | 6x4 |
| Cab | Flattop metal forward turnover |
| Wheelbase | 4325+1350mm |
| Max. speed | 90km/h |
| Min. turning diameter | <22m |
| Approach angle | 16° |
| Departure angle | 12° |
Liquid tank |
| Capacity | Water: 10000kg Foam: 2000kg |
| Material | 304 high quality corrosion resistant plate |
| Structure | Total side girder |
| Device |
2 ingates 1 overflow device 2 liquid level sensor 2 DN50 drain outlet with valve 4 filling pipe end Conform to rule GA39.4-92 |
Side girder
Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.
Dash board and on-board equipment
Cab PTO gear switch
Pump room
| Function switch | lighting, water outlet, water injection, liquid outlet, monitor shot |
| Dash board | Pressure gauge, Water gauge, vacuum gauge, content gauge, tachometer |
