4x2 Drive 6 Cylinder Diesel Engine 25m Working Height Aerial Ladder Fire Truck
4x2 Drive 6 Cylinder Diesel Engine 25m Working Height Aerial Ladder Fire Truck
Main parameters and configuration
1, vehicle
| Dimensions | 8650 * 2450 * 3500 mm |
| Full load allowed total mass | 17400 kg |
| Vehicle kerb mass | 15700 kg |
| The number of passengers | 2(including the driver) (person) |
| Maximum power | 177/240 kW/hp |
2, chassis
2.1 manufacturer: Isuzu
2.2 Isuzu FTR34L
2.3 drive form: 4X2
2.4 cab: single row cab
2.5 wheelbase (mm): 4250
2.6 chassis weight: 4710 Kg
2.7 maximum allowable load: 12700Kg
2.10 engine: 6 cylinder diesel engine
2.11 type: 6HK1-TCN
2.12 maximum engine power: 177Kw/ 2400r/min
2.13 maximum torque: 706N.M/1450rpm
2.15: single, dry clutch
2.16 transmission: MZW6P
2.17 taking full power: broken shaft type
2.18 transmission power: customers with
3. Equipment & Spare parts
| no | name and model | unit | qty. | remarks |
| 1 | o ring 14×2.65G | pcs | 6 | GB/T3452.1-1992 |
| 2 | ring 11.2×2.65G | pcs | 4 | GB/T3452.1 |
| 3 | ring 22.4×2.65G | pcs | 4 | GB/T3452.1 |
| 4 | ring 71×3.55G | pcs | 1 | GB/T3452.1 |
| 5 | ring 118×5.3G | pcs | 1 | GB/T3452.1 |
| 6 | ring 150×3.55G | pcs | 1 | GB/T3452.1 |
| 7 | ring 140×5.3G | pcs | 3 | GB/T3452.1 |
| 8 | ring 128×5.3G | pcs | 1 | GB/T3452.1 |
| 9 | checking switch SZL-WL-A | pcs | 1 | |
| 10 | travel switch SZL-WL-B | pcs | 1 | |
| 11 | travel switch SZL-WL-E | Pcs | 1 | |
| 12 | fuse tube 5×20 | Pcs | 10 | 10A |
| 13 | fuse tube 5×20 | pcs | 20 | 20A |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
