25 Meters Max Height Short Adjustment Time Aerial Ladder Fire Truck 4x2 Drive
25 Meters Max Height Short Adjustment Time Aerial Ladder Fire Truck 4x2 Drive
Main parameters and configuration
1, vehicle
1.1 dimensions: length * width * width * height (mm) 8650 * 2450 * 3500
1.2 full load allowed total mass (kg): 17400
1.3 vehicle kerb mass (kg): 15700
1.4 the number of passengers (including the driver) (person): 2
1.5 maximum power (kW/hp): 177/240
2, chassis
2.1 manufacturer: Isuzu
2.2 Isuzu FTR34L
2.3 drive form: 4X2
2.4 cab: single row cab
2.5 wheelbase (mm): 4250
2.6 chassis weight: 4710 Kg
2.7 maximum allowable load: 12700Kg
2.10 engine: 6 cylinder diesel engine
2.11 type: 6HK1-TCN
2.12 maximum engine power: 177Kw/ 2400r/min
2.13 maximum torque: 706N.M/1450rpm
2.15: single, dry clutch
2.16 transmission: MZW6P
2.17 taking full power: broken shaft type
2.18 transmission power: customers with
tools
| No. | name and model | Unit | qty. | remarks |
| 1 | internal hexagonal wrench3～17 | suit | 1 | GB/T5356-1998 |
| 2 | monkey wrench150×18 | pcs | 1 | GB/T4440-1998 |
| 3 | monkey wrench300×36 | pcs | 1 | QB/T2564.4-2002 |
| 4 | straight screwdriver50×0.4×2.5I-1P | pcs | 1 | QB/T2564.4 |
| 5 |
straight screwdriver 125×0.8×5.5I-1P |
pcs | 1 | QB/T2564.4 |
| 6 | straight screwdriver250×1.6×10I-1P | pcs | 1 | QB/T2564.4 |
| 7 | cross screwdriver175C | pcs | 1 | QB/T2564.4 |
| 8 | cross screwdriver3150C-H | pcs | 1 | QB/T2564.4 |
| 9 | press bar type grease gun | pcs | 1 | QB/T2564.4 |
| 10 | hammer 0.88kg | pcs | 1 | QB/T2564.4 |
| 11 | wire cutter 180mm | pcs | 1 | QB/T2564.4 |
| 12 | pipe wrench 300 Ⅲ Z | pcs | 1 | QB/T2564.4 |
| 13 | slip-joint plier165mm | pcs | 1 | QB/T2564.4 |
