6475kg Whole Weight 4x2 Drive Aerial Work Platform Truck with 18M Telescopic Boom
6475kg whole weight KaiFan Brand 18M Telescopic Boom (ISUZU) Aerial Working Platform 4x2 drive
KFM5079JGK10S Telescopic Boom Aerial Working Platform can be applied in various conditions for aerial working, such as urban road, suburban road, highway, airport, bridges and culverts and so on. The structure type is telescopic boom and the lifting boom is flexible, convenience and performance with the negative point, more suitable for narrow site conditions or other special operations.
1. Main Parameters
| Bulletin No. | KFM5079JGK10S | |
| External dimensions(mm) | 8010×2000×2950 | |
| Structure type | Three-section telescopic boom | |
| Working Cage | Internal size(mm) | 1100×700×1100 |
| Rated loading(kg) | 200(or 2 persons) | |
| Max. Working height(mm) | 18000 | |
| Max. Height from ground(mm) | 16300 | |
| Max. Working radius(mm) | 12000 | |
| Basket insulated (V) | 10000 | |
| Rotation angle(º) | ±90° | |
| Working Boom | Lifting angle of main boom(º) | -13—78° |
| Boom rack rotation angle(º) | 360 | |
| Outrigger | Vertical span(mm) | 3930 |
| Horizontal span(mm) | 3980 | |
| Adjustment | Single adjustable | |
2. Chassis Introduction
Traveling | Chassis model | ISUZU NKR77PLLWCJAY |
| Persons | 2+3 | |
| Axle base (mm) | 3815 | |
| Wheel base (front/rear)(mm) | 1504/1425 | |
| Driving mode | 4×2 | |
| Front suspension(mm) | 1504 | |
| Rear suspension(mm) | 2470 | |
| Approaching angle(º) | 24 | |
| Departure angle(º) | 10 | |
| Min. Turning diameter(mm) | 14000 | |
| Min. Ground clearance(mm) | 190 | |
| Engine | Engine model | 4KH1-TC |
| Rated power(Kw/r/min) | 96/3400 | |
| Torque(N,m/r/min) | 280/1700 | |
| Max. Speed(km/h) | 70 | |
| Specification of the tire | 7.00-16 | |
| The whole weight(kg) | 6475 | |
| Max. Weight with whole loading(kg) | 6800 | |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
