2 Boom Sections Flatbed Road Wrecker Truck Diesel Fuel Payload 3000kg
Price:
USD
MOQ:
1 SET
Delivery Time:
30 working days
Brand:
YD
Product Description
2 Boom Sections Flatbed Working Road Wrecker Diesel Fuel Payload 3000kg
The tow wrecker is called the road wrecker, also known as road rescue vehicle. It has many functions such as lifting, pulling and lifting traction. The wrecker is mainly used for road fault vehicles and urban illegal vehicles, rescue and so on. The wreckers are mainly divided into: towed joint type, towed separation type, one to one type, flat one to two type, multi-purpose wrecker, hydraulic automatic clamping type.
Brand available: ISUZU, Dongfeng, JMC, JAC, Steyr, Iveco etc.
Ton:2 tons, 3 tons, 5 tons, 8 tons, 10 tons, 15 tons, 25 tons, 30 tons, 50 tons, 60 tons.
Driving type: 4x2, 6x4, 8x4 left hand drive / right hand drive
Brand available: ISUZU, Dongfeng, JMC, JAC, Steyr, Iveco etc.
Ton:2 tons, 3 tons, 5 tons, 8 tons, 10 tons, 15 tons, 25 tons, 30 tons, 50 tons, 60 tons.
Driving type: 4x2, 6x4, 8x4 left hand drive / right hand drive
| Vehicle | 4*2 Dongfeng Flatbed Wrecker Truck |
| Brand | DFAC |
| Cab | Single row |
| Vehicle Description | |
| Overall dimensions(mm) | 7420*2300*2950 |
| G.V.W (kg) | 7490 |
| Curb weight(vehicle) (kg) | 5295 |
| Loading capacity (kg) | 3000-5000 |
| Max speed (Km/h) | 95 |
| Engine Description | |
| Engine model | CY4102-C3C |
| Maximum power | 88kw/120hp |
| Displacement (lit) | 3856 |
| Engine Manufacturer | Chaochai Diesel Manufacture |
| Chassis Description | |
| Chassis Model | EQ1070TJ9AD3 |
| Wheel base(mm) | 3800 |
| F/R track base(mm) | 1835/1640 |
| F/R overhang(mm) | 1180/2440 |
| Spring plate | 11/9+7 |
| Front axle / rear axle(t) | 2.2/5 |
| Type of fuel | Diesel |
| Gear box | 6-speed with over drive |
| Brake system | Air braking |
| Operation control system | Power Steering |
| Electric system | 24V |
| Tyres&Tire quantity | 7.50-16 & 6+1 |
| Crane Description | |
| Model | SQ3.2SK2Q |
| Max Lifting Capacity (kg) | 3200 |
| Max Lifting Moment (T.M) | 6.72 |
| Crane Weight(kg) | 1105 |
| Installation Space(mm) | 850 |
| Max. Operating Diameter (m) | 7.5 |
| Max. Lifting Height (m) | 9.5 |
| Max Pressure of Hydraulic System(MPa) | 20 |
| Oil Tank Capacity | 30 |
| Rotation Angle | All Rotation 360° |
| Boom Section | 3 |
| Special performance&Equipment | |
| Payload 3000kg Rated Pull Force of Winch 40 KN Min. Inclination Angle 12° UNDER-LIFT Max. lift weight (retracted) 1600kg Max. lift weight (extended) 1100 kg Rated towing capacity 6400kg |
|
