Galvanized Steel Sheet Outdoor Telecom Cabinet , Waterproof Outdoor Electrical Enclosure
Galvanized Steel Sheet IP55 Outdoor Cabinet of Telecom Equipment and Battery
Quick Details:
| nternal dimension(W*D*H) | 800mm*800mm*1800mm |
| External dimension(W*D*H) | 905mm*1080mm*2105mm |
| Floor area(W*D) | 905mm*905mm |
| Base height | 200mm |
1. Brief Introduction:
CONSNANT Outdoor Integrated Cabinet product includes two series, one is functional cabinet that covers power cabinet, electronics cabinet and battery cabinet; the other is 1U holding cabinet(outdoor macro site, RRU),2U holding cabinet, 3U holding cabinet
2. Product features:
- Small volume, easy to to find the site.
Single cabinet covers an area of less than 1 square meter. The site is easy to obtain, so the cabinet can be applied to the top of the hill, roof, street and other scenes;；
- Subdivision temperature control, energy conservation and emission reduction
Fine sub-class temperature control save energy maximumly; cabinet with insulated sandwich panels weaken the impact of solar radiation on the cabinet temperature
- Modular design, fast provision
Modular design support bulk shipment and site installation, and easy to expand
- Strong structure, good rust-proof capacity
Aluminum profile frame structure, outside panel adopts color steel panel with excellent performance of antiseptic, passing the salt spray test for 960H.
- Flexible housing and strong adaptability
Support the installation of main equipment, transmission equipment, power supply, battery and other equipment from different manufacturers and different installation methods.
Specification:
| Item | Specification |
| Weight | 105KG( not including electronics and battery) |
| User space | 40U |
| Flame material | Galvanized steel sheet |
| Wall material | Color steel sandwich panel: color steel+polystyrene(polyurethane PU optional) |
| Wall thick | 45mm |
| Door lock | Three point security locks,European standard , |
| IP | IP55 |
| Cable laying arrangement. | 8*Φ50mm |
| Delivery form | Fully equiped |
| Operating temperature | -40℃～+70℃ |
| Cabinet relative humidity | 5%～100% |
| Air Circulation & Heat exhaust arrangement | |
| Temperature control | PC300 |
| TCO2 power dissipation | 230W @L35/L35 |
| TCO2 refrigerating capacity | 400W @L35/L35 |
| Heater power consumption(optional) | 500W |
| Battery information | |
| Specification | 650AH 2V/150AH 12V AGM battery |
| Capacity | 650AH/600AH |
| Group | 1/*4 groups |
| Others | |
| Illumination | -48V LED light |
Remarks: Fully Customized! Supply what you really need!
