Galvanized Steel Sheet IP55 Outdoor Cabinet Water Proof High Reliability Modular Design
Modular Design IP55 Outdoor Cabinet With Good Rust-proof Capacity
Key Features:
- Adopt advanced MCU microprocessor control technology.
- Advanced MPPT Technology ,High converting efficiency higher than 97% for minimazing energy loss.
- Reversed current protection at night,over voltage and reverse polarity protection.
- Capable of selecting different charging mode for various types of batteries.
- Protection degree:IP55
- Industy-leading power density compact size and high reliability.
- Doorframe designed with waterproof structure,posted on the seal and equiped with waterproof lock on the door double insulation design.
- Cabinet adopt quality galvanized sheet or aluminum coated steel sheet as material,surface ocating anti-UV power.
- Suitable for outdoor installation.
Advantages:
- Small volume, site can be obtained easily.
Single cabinet covers area < 1 square meter. The site is easy to obtain, so the cabinet can be applied to the top of the hill, roof, street and other scenes;
- Flexible housing and strong adaptability
Support the installation of main equipment, transmission equipment, power supply, battery and other equipment from different manufacturers and different installation methods.
- Subdivision temperature control, energy conservation and emission reduction
Fine sub-class temperature control save energy maximumly; cabinet with insulated sandwich panels weaken the impact of solar radiation on the cabinet temperature
- Modular design, convenient provision
Modular design support bulk shipment and site installation, and easy to expand
- Good rust-proof capacity, strong structure
Aluminum profile frame structure, outside panel adopts color steel panel with excellent performance of antiseptic, passing the salt spray test for 960H.
Quick Details:
| Internal dimension(W*D*H) | 800mm*800mm*1800mm |
| External dimension(W*D*H) | 905mm*1080mm*2105mm |
| Floor area(W*D) | 905mm*905mm |
| Base height | 200mm |
Specification:
| Item | Specification |
| Weight | 105KG( not including electronics and battery) |
| User space | 40U |
| Flame material | Galvanized steel sheet |
| Wall material | Color steel sandwich panel: color steel+polystyrene(polyurethane PU optional) |
| Wall thick | 45mm |
| Door lock | Three point security locks,European standard , |
| IP | IP55 |
| Cable laying arrangement. | 8*Φ50mm |
| Delivery form | Fully equiped |
| Operating temperature | -40℃～+70℃ |
| Cabinet relative humidity | 5%～100% |
| Air Circulation & Heat exhaust arrangement | |
| Temperature control | PC300 |
| TCO2 power dissipation | 230W @L35/L35 |
| TCO2 refrigerating capacity | 400W @L35/L35 |
| Heater power consumption(optional) | 500W |
Remarks: Fully Customized! Supply what you really need! The Specification is for reference.
