630KW Touch Screen Bidirectional Battery Inverter IP20 Solar Charger
Price:
Negotiable
MOQ:
1Uint
Delivery Time:
15 days after receiving 30% deposit
Brand:
CONSNANT
Product Description
Bidirectional battery inverter from 50KW to 630KW,can be used alone or with solar charge and other accessories
Features
- Flexible Configuration
Configured with solar charge controller, bypass cabinet or stand alone.
- Programmable working mode
Pak-shaving, back-up, use the system however you want it
- Scalable
Applicable in MW level system by paralleling multiple units
- Touchscreen LCD
More convenient for parameter setting and maintenance
- Dry contact output
Supports remote control of DG
Specification
| CNS SPS50 | CNS SPS100 | CNS SPS 250 | CNS SPS 500 | CNS SPS 630 |
| AC(grid-connected) | |||||
| Apparent power | 55kva | 110kva | 275kva | 550kva | 693kva |
| Rated power | 50KW | 100KW | 250KW | 500KW | 630KW |
| Rated voltage | 400V | ||||
| Rated current | 72A | 144A | 361A | 722A | 909A |
| Voltage rated | 310V-450V | ||||
| Rated frequency | 50/60HZ | ||||
| Frequency range | 45-55/55-65HZ | ||||
| THDI | <3% | ||||
| PF | 0.8 lagging-0.8leading | ||||
| AC connection | 3/N/PE | ||||
| AC(Off-grid) | |||||
| Apparent power | 55KVA | 110KVA | 275KVA | 550KVA | 693KVA |
| Rated power | 50KW | 100KW | 250KW | 500KW | 630KW |
| Rated voltage | 400V | ||||
| Rated current | 72A | 144A | 361A | 722A | 909A |
| THDU | <=2%linear | ||||
| Rated frequency | 50/60HZ | ||||
| Overload capacity | 110%-10min 120%-1min | ||||
| DC(battery and PV) | |||||
| Rated power | 50KW | 100KW | 250KW | 500KW | 630KW |
| Current regulation | ±1% | ||||
| Voltage regulation | ±1% | ||||
| Voltage ripple | <3% | ||||
| Current ripple | <2% | ||||
| Rated voltage | 600VDC | 600VDC | 600VDC | 700VDC | 700VDC |
| Voltage range | 500V-820V | 600V-900V | |||
| Rated current | 84A | 167A | 417A | 714A | 900A |
| General information | |||||
| Max.efficiency | 95.5% | 97.1% | 97.3% | 98.5% | 98.5% |
| Protection degree | IP20 | ||||
| Noise emission | <65db(A)@1m | ||||
| Environment teperature | -25℃…+55℃ | ||||
| Cooling | Forced-air | ||||
| Relative humidity | 0-95%non-condensing | ||||
| Max.altitude | 6000m(derate over 3000m) | ||||
| Dimension(W*H*D) | 600*1630*800mm | 1100*1890*850mm | 1600*2080*850mm | 1200*1900*800mm | 1200*1900*800mm |
| Weight | 450kg | 820kg | 1465kg | 900kg | 900kg |
| Build-in transfer | Yes | Yes | Yes | NO | NO |
| Transfer between on/off grid | Manual(default)Automatic(optional)<=10ms | ||||
| Communication | |||||
| Display | Touch screen | ||||
| Communication interface | RS485/CAN | ||||
| Certificate | CE,MEA,PEA,EN,IEC | ||||
