1250kg counterbalanced electric stacker warehouse forklift trucks mast reach type


Quick Details:

Model: Reach type electric warehouse forklift trucks CQD12R
​​​Capacity: 1250kg
Lift height: 2500-5500mm
Fork dimensions: 35/100/950(1070/1150)mm

​Aisle width for pallets: 2650mm

​Turning radius: 1650mm
Travel speed, load/unload: 6.8/7km/h​
Battery: 24V270Ah

​Service weight: 1800kg


Advantages:

• With short handle and standing structure, the steering is light and flexible, and has good handling performance (imported handle assembly).
• Two lifting cylinders are adopted, and the lifting oil cylinder and the chain are mounted on both sides of the mast, which improves the lateral stability of the cargo lifting and widens the vision of the operator.
• The portal mast column material is the special type of imported high lift steel.
• The forks have the function of front and back tilting, which is beneficial to the loading, unloading and stacking operation of goods.
• The reach type warehouse forklift trucks has compact structure, low center of gravity and good steering stability.
• Large capacity battery to ensure strong and lasting power.
• The AC variable frequency traction motor has the advantages of compact structure, high performance, regenerative braking and easy maintenance.
• Import AC control system, sensitive response, reduce maintenance and noise, both from low speed to high speed or high speed to low speed have strong control ability.
• Low voltage protection, prolong the service life of battery.
• The vertical driving wheel has the advantages of low noise, high transmission efficiency, convenient installation and maintenance.
• The braking system is reliable, the electromagnetic brake is combined with regenerative braking, which greatly prolongs the service life of the friction plate.
• Reliable multi-channel valve hydraulic control system, with lifting, front and back movement, front and rear tilt function.
• Built in charger, free lifting, fork side shift, can be used as customer selection.
• Adjustable lower speed control valve can adjust the speed of the mast lowering.
• Back of the  mast fitted with rubber shock pad, to prevent the mast after the impact time, reduce noise.
• High lift triplex mast mounting height limit switch, ensure warehouse forklift trucks stability and safety performance of L.
• The power box cover is pulled by magnet and has no screw fixation, so it is easy to install and disassemble.
• Maintenance is convenient, the battery box can be maintained only by opening the power box cover, and it is convenient to add the hydraulic oil to the front tank.
• No baffle on both sides of the storage battery is beneficial to the heat dissipation of the battery, and the hoisting is convenient and safe.
• Low noise.
