Double Scissors Narrow Aisle Truck Reach Type Capacity 1000kg Low Battery Protection
Price:
Negotiable
MOQ:
1 set
Delivery Time:
25 - 30 days
Brand:
REACH
Product Description
1000kg electric narrow aisle truck fork reach type with double scissors
Quick Details:
Product name: Electric narrow aisle truck double scissors CQDH15C
Capacity: 1000kg
Lifting height: 3000/3500/4000mm
Reach distance: 1200mm
Aisle width for pallets 1000*1200 crossways: 2951mm
Aisle width for pallets 800*1200 lengthways: 3034mm
Turning radius: 1718mm
Battery: 24V 420(560)AH
Advantages:
-
Double scissors forks.
-
Capacity 1000kg.
-
Lifting height 3000mm to 4000mm.
- Long reach distance 1200mm.
-
Low battery protection setting prolongs the battery use time.
-
CANbus technology reduces wiring complexity and increase reliability.
-
All pivot points have grease fitting and serviceable bushing, reducing component wear and extending component life.
-
The back cover is easy to open for maintenance and adjustment of parts of valve, oil tube and electronic parts.
| SPECIFICATIONS | ||
| Model | CQDH15C | |
| Power | battery | |
| Load capacity/rated load | kg | 1000 |
| Load center distance | mm | 500 |
| Load distance, centre of drive axle to fork | mm | 159 |
| Tyre size, front | mm | 280*82+160*60 |
| Tyre size, rear | mm | 125*82 |
| Tilt of mast/fork carriage forward/backward | Grad | 2/5 |
| Height, mast lowered | mm | 2125/2375/2625 |
| Free lift | mm | ~ |
| Max. lifting height | mm | 3000/3500/4000 |
| Height, mast extended | mm | 4035/4535/5035 |
| Height of overhead guard | mm | 2246 |
| Overall length | mm | 2585 |
| Overall width | mm | 1308/1040 |
| Length to face of forks | mm | 1515 |
| Fork dimensions | mm | 35/100/1070 |
| Reach distance | mm | 1200 |
| Fork height, lowered | mm | 130 |
| Distance of "X" | mm | 350 |
| Overall length(excluding the fork) | mm | 1868 |
| Ground clearance, centre of wheelbase | mm | 65 |
| Aisle width for pallets 1000*1200 crossways | mm | 2951 |
| Aisle width for pallets 800*1200 lengthways | mm | 3034 |
| Turning radius | mm | 1718 |
| Travel speed, laden/unladen | km/h | 6.5/7 |
| Lift speed, laden/unladen | m/s | 0.135/0.16 |
| Lowering speed, laden/unladen | m/s | 0.15/0.12 |
| Battery | V/Ah | 24/420(560) |
| Service weight | kg | 2480/2530/2590 |
