Thickness 0.2 - 0.5mm Metal Cold Roll , Precision 301 Stainless Steel Strip Stock

Price Negotiable

Price: negotiation

MOQ: negotiation

Delivery Time: 4-5 weeks

Brand: Yongjin

Product Description

Thickness 0.2-0.5mm precision cold rolled stainless strips grade 301

Description	Precision cold rolled stainless steel coils/CR stainless steel strips
Grade	301
Thickness	0.2-0.5mm
Finish	BA1
Width	10-650mm
Standard	JIS ASTM AISI ASME
Surface treatment	Cold rolled,annealed, pickled
Mill	YONGJIN
Grade	Prime
Country of Origin	made in China
Payment terms	by T/T or L/C
Packaging	Seaworthy standard export package with pallet
Shipping date	30-45dd
Shipping terms	FOB CFR CIF etc.

The 301 is the most widely used stainless steel, heat-resistant steel. The application consists in food production equipment, general chemical equipment, nuclear power etc. Compared with 304 stainless steel,301 material contains a lower Cr and Ni element,cold processing tensile strength and hardness increased, no magnetic, but is magneticafter cold processing . Purpose: train, aircraft, conveyor belt, vehicle, bolt, nut, spring, filters etc

CHEMICAL COMPOSITION

Standard	GRADE	C	Si	Mn	P	S	Ni	Cr	N
JIS	SUS301	≤0.15	≤1.00	≤2.00	≤0.045	≤0.030	6.00-8.00	16.00-18.00	.......
ASME	S30100	≤0.15	≤1.00	≤2.00	≤0.045	≤0.030	6.00-8.00	16.00-18.00	≤0.10
EN	1.4319	≤0.07	≤1.00	≤2.00	≤0.045	≤0.030	6.00-8.00	16.00-18.00	≤0.11

Main Application for grade 301 strips

No.	Application	Application components	Thickness
No.	Application	Application components	(mm)
1	Aerospace Industry	Helicopter connector	0.10～0.40
2	IT industry	Button shrapnel	0.05～0.13
		Hard disk switch	0.05～0.20
		Terminal spring	0.08～0.20
3	Mobile phone industry	Internal structural components	0.05～0.5
4	Chemical etching industry	All kinds of precision component	0.10～0.20
5	Gasket	Motor vehicles, engines and Petrochemicals	0.10～0.30
5	Gasket	All kinds of gasket for industrial use	0.10～0.30
6	Camera industry	Spring and shutter disk	0.05～0.30
