ASTM 309S Stainless Steel Strip Coil Mill Edge / Slit Edge Prime Grade
Quick Detail:
Stainless steel strip coil/CR stainless steel strips/Cold rolled stainless steel coils
| Description | Stainless steel strip coil/CR stainless steel strips/Cold rolled stainless steel coils |
| Grade | 309S |
| Thickness | 0.3-3.0mm |
| Finish | 2B 2D BA No.3 No.4 HL |
| Width | 1000/1030/1219/1240/1250/1500/1530/1550mm |
| Edge | slit edge/mill edge |
| Standard | ASTM |
| Coil ID | 508/610mm |
| Thickness tolerance | to be defined with customers |
| Surface treatment | Cold rolled,annealed, pickled |
| Coil weight | 4-22MT or as per clients request |
| Q'ty tolerance | +/-10% on order quantity |
| Paper Interleaved | Yes |
| Country of Origin | made in China |
| Payment terms | by T/T or L/C |
| Packaging | Seaworthy standard export package with pallet |
Finish Definition:
No.2D: Cold-rolled, annealed and pickled without skinpass. the dull products can be used as automobile parts,building materials and pipes
No.2B: The surface brightness and flatness of No.2B is better than No.2D. Then through a special surface treatment to improve its mechanical properties. No.2B could nearly satisfy comprehensive uses.
No.3: Polished with abrasive belt of grit #100-#120, have better brightness with discontinuous coarse stria, used as inner and external ornaments for building.electrical applicances and kitchen utensils etc.
No.4: Polished with abrasive belt of grit #150-#180, have better brightness with discontinuous coarse stria,but thinner than No.3, are used as bathtub building's inner and external ornaments electrical appliances,kitchen utensiles and food processing equipment etc .
HL: Polished with abrasive belt of grit#150-#320 on the No.4 finish and has continuous streaks, mainly used as building's ornaments,elevators,door of building,frontal plate etc.
BA: Cold rolled,brigth annealed and skin-passed, the product have excellent brightness and good reflexivity like mirror,used for electrical applicances,mirrowr,kitchen apparatus,ornament materials etc.
Chemical Composition and Mechanical Properties
| Type | Grade | Chemical Composition(%) | ||||||
| C | Si | Mn | P | S | Ni | Cr | ||
| 309S | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 12.00～15.00 | 22.00～24.00 | |
| Mechanical Properties | ||||||||
| Material | Yield Point | Tensile Strength | Elongation | Hardness | ||||
| YS0.2(Kg/mm2) | TS(Kg/mm2) | EL(%) | HRB | HV | ||||
| 309S | 205 | 520 | 40 | 200 | 90 | |||
Standard Export Packing:
1. Protection paper between each coil loop
2. Internal wrapped with water proof paper and protection cardboard
3. Internal and external metallic corner.
4. Wrapping bands: No.3 Circumferential straps +No.4 radial straps
5. Locked by wire buckled
6. With pallet, and pallet is fumigated.
