Durable 2205 Duplex Stainless Steel Plate , Standard Astm Stainless Steel Plate
Duplex stainless steel E2205 hot rolled stainless steel plate 4.0mm~30mm
Product
| Grade | GB/T4237 | ASTM A240 | EN10088 |
| E2205 | 022Cr23Ni5Mo3N | 2205 | 1.4462 |
E2205 Hot Rolled Stainless Steel Plate
| Commodity | E2205 Hot Rolled Stainless Steel Plate |
| Grade | E2205 |
| Length | 3000m,6mmm, or as per your request |
| Thickness | 4.0-30mm |
| Width | <1600mm |
| Place of Origin | Zhejiang,China |
General Properties
E2205 duplex stainless steel(DSS) is characterized by a dual phase structure with approximately equal volume fractions of both ferrite and austenite,offering an attractive combination of corrosion resistance,higher mechanical properties,excellent impact toughness and welding performace.
The yield strength is about twice that of austenitic stainless steels.This allows a designer to save weight and makesthe alloy more cost compettive when compared to 316L.
Chemical Composition
The typical chemical composition of E2205 duplex stainless steel are showed in the following table. Among the standard of GB,ASTM and EN, the range of the chemical composition of E2205 has a slightly different.
| CHEMICAL COMPOSITION(%) | GB/T4237 | ASTM A240 | EN10088 | |
| C (max) | 0.03 | 0.03 | 0.03 | |
| Si (max) | 1.00 | 1.00 | 1.00 | |
| Mn (max) | 2.00 | 2.00 | 2.00 | |
| P (max) | 0.03 | 0.03 | 0.035 | |
| S (max) | 0.02 | 0.02 | 0.015 | |
| Mo | 3.00~3.50 | 3.0-3.50 | 2.50-3.50 | |
| N | 0.14~0.20 | 0.14-0.20 | 0.10-0.22 | |
| Cr | 22.00~23.00 | 22.00-23.00 | 21.00-23.00 | |
| Ni | 4.50-6.50 | 4.50-6.50 | 4.50-6.50 | |
Mechanical Properties
| Standard | GB/T4237 | ASTM A240 | EN10088 | |
| GRADE | 022Cr19Ni10 | 304L | 1.4307 | |
| Yield Strength | (N/mm2) | 450 | 450 | 460 |
| Tensile Strength | (N/mm2) | 620 | 655 | HRC700-950 |
| Elongation | (%) | 25 | 25 | 25 |
| Hardness | HRC | 31 | - | 92 |
Processing
There are high-tech equipments to processing stainless coils and sheets/plates with skilled workers.
- Cut to length
- Decoiling and slitting
- Grinding and brushing
- Film protection
- Plasma and water jet cutting
- Folding and embossing
