Custom Size Embossed Stainless Steel Panels , Decorative Stainless Steel Sheets
Embossed stainless steel sheet & plate
Stainless Steel Embossed sheet & plate
Features
1. After embossing process, the intensity of the sheets have got increased, the fighting strength and compressive strength also get improved comparing the normal ones.
2. Decreased 30%-70% friction and enhanced sliding efficiency of the surface dramatically,It is suitable for the transmission of the powder making, food and medicine as well as packing equipments.
Quick Detail:
Material: 201,202, 304, 430. 439,316 and so on.
Thickness: 0.4-1.5mm
Normal size: 1000mm*2000mm. 1219mm*2438mm
Customerized size
Length: 500mm-6500mm
Width: 100mm-1250mm
Tolerance: length, width: +0.5mm
cater-corner:<0.5mm
CHEMICAL COMPOSITION
| STANDARD | GRADE | CHEMICAL COMPOSITION % | ||||||
| C max | Si max | Mn max | P max | S max | Ni | Cr | ||
| Mill Standard | 201 | 0.15 | 0.80 | 9.00 | 0.060 | 0.030 | ≥1.00 | ≥13.00 |
| JIS G4305 | SUS202 | 0.15~0.25 | 1.00 | 8.00~10.00 | 0.06 | 0.03 | 3.70~5.00 | 12.00~14.00 |
| JIS G4305 | SUS301 | 0.15 | 1.00 | 2.00 | 0.045 | 0.03 | 6.00~8.00 | 16.00~18.00 |
| JIS G4305 | SUS304 | 0.08 | 1.00 | 2.00 | 0.045 | 0.03 | 8.00~10.50 | 18.00~20.00 |
| JIS G4305 | SUS316L | 0.03 | 1.00 | 2.00 | 0.045 | 0.03 | 12.00~15.00 | 16.00~18.00 |
| JIS G4305 | SUS430* | 0.12 | 0.75 | 1.00 | 0.040 | 0.03 | - | 16.00~18.00 |
| JIS G4305 | SUH409L● | 0.03 | 1.00 | 1.00 | 0.040 | 0.03 | - | 10.50~11.75 |
| JIS G4305 | SUS420J2 | 0.26~0.40 | 1.00 | 1.00 | 0.060 | 0.03 | - | 12.00~14.00 |
| JIS G4305 | SUS436L | 0.025 | 1.00 | 1.00 | 0.040 | 0.03 | - | 16.00-19.00 |
Main applications
1. Building, elevator decoration
2. Home appliances, kitchen ware
3. Industrial and medical instruments
