1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
Price:
negotiation
MOQ:
negotiation
Delivery Time:
within 4 weeks
Brand:
JUYE
Product Description
Quick Detail:
Description: Stainless steel welded pipe
Grade: 321
Standard: EN10217-7:2005
Gauge:13.50-410mm
Wall thickness:1.20-14.20mm
Size: see here below attached table "size range"
Size Range
| Gauge(mm) | Nominal Wall Thickness(mm) | ||||||||||||||||
| 1.20 | 1.60 | 2.00 | 2.30 | 2.60 | 2.90 | 3.20 | 3.60 | 4.00 | 4.50 | 5.00 | 5.60 | 6.30 | 7.10 | 8.00 | 8.80 | 10.00 | |
| 13.5 | ● | ● | ● | ● | |||||||||||||
| 17.2 | ● | ● | ● | ● | |||||||||||||
| 21.3 | ● | ● | ● | ● | ● | ||||||||||||
| 26.9 | ● | ● | ● | ● | ● | ● | |||||||||||
| 33.7 | ● | ● | ● | ● | ● | ● | ● | ||||||||||
| 42.4 | ● | ● | ● | ● | ● | ● | ● | ● | |||||||||
| 48.3 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||||||
| 60.3 | ● | ● | ● | ● | ● | ● | ● | ● | |||||||||
| 76.1 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||||||
| 88.9 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | |||||||
| 101.6 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | |||||||
| 114.3 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||||
| 139.7 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||||
| 168.3 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | |||||
| 219.1 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||
| 273 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||||
| 323 | ● | ● | ● | ● | ● | ● | ● | ● | |||||||||
| 355.6 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||||||
| 406.4 | ● | ● | ● | ● | ● | ● | ● | ● | ● | ||||||||
Chemical Composition
Standard: EN10217-7
Grade:1.4541
C: 0.08%
Si:1.00%
Mn:2.00%
P:0.045%
S:0.03%
Ni:9%~13%
Cr:17%~19%
Ti:5*C%
Mechanical Characteristics
| EN10217-7 | Grade | Yield Strength | Tensile Strength | Elongation | Hardness |
| N/mm2 | N/mm2 | % | HRB | ||
| 1.4541 | ≥205 | ≥520 | ≥40 | ≤90 |
Advantage of Stainless Steel Fluid Pipe
The stainless steel fluid pipe is safe, reliable, sanitary, environmental friendly, economical and applicable. The pipe wall is thin, and the connection method is simple and convenient
Main Application:
- Petrochemical
- Papermaking
- Energy
- Steam
- Sewage Engineering
