Adjustable Triple Wire Suspension Kit , SS 304 Cable Hanging System

The ceiling suspension kit is easily fitted to a ceiling or underneath any horizontal surface, using the screw and plug kit provided (depending on the surface). You must ensure that the surface you are screwing into is capable of holding the weight of the item you are intending to hang.

This wire suspension kit contains all the comopents to suspend as following:

1. Ceiling Attachment ;

Material:Brass plated in Nickel

Size:Ø15*15mm

2. 304 Stainless Steel Wire with eyelet diecast;

Size:Ø1.5*3000mm

3. Cable Gripper made from brass material with Nickel plated;

Size:Ø13*44mm,can hold three cables

To hang your light fixtures is as easy as ever with the Self-Gripping Ceiling Fastener!
You can use the Ceiling Attachment to mount your cable to the ceiling,
Fixed the cable to the application with the external thread of the cable gripper.

Adjusting the position of the gripper is as simple as pressing down the button on the top of the gripper, then sliding it into the desired location and releasing the button.

Description

IMPORTANT: It is essential to check that the top ceiling fixings are strong enough to take the

weight of the items being displayed, while allowing for the tension in the cables.

Affix fitting ceiling attachment to ceiling:

- for wooden ceilings use a wood screw.

- for cavity ceilings use a spring toggle bolt.

- for solid ceilings use a rawl plug and screw.

Confused about how to select your hanging system?

1. Choose a Suspension Point
Your system can be ceiling or wall mounted, with applications

hanging freely or tensioned between two fixed points;

2. Pick a Cable
Our stainless steel aircraft cable comes in several diameters

and lengths ranging from 1.0mm~3.0mm;

3. Select a Gripper
A range of designs and options, all with self gripping technology,

offer a secure and elegant solution for any fine art installation.
