New Style ESD Air Gun , Safety Anti Static Air Nozzle For Printing / Packaging
New Style Durable Safety High Quality ESD Antistatic Ionizing Air Gun
HOYATO-301A Generation 4.5 mechanical and intelligent ionizing air gun is kapper’s latest developed and produced intelligent anti-static devices, it can eliminate the static electricity on object surfaces.
HOYATO-301A Generation 4.5 mechanical and intelligent ionizing air gun is a hand-held electrostatic eliminator, often used to eliminate electrostatic dust, and it’s only useable with compressed air and 4.6 KV HOYATO-401A Generation 4.6 mechanical and intelligent high voltage power supply.
HOYATO-301A Generation 4.5 mechanical and intelligent ionizing air gun can produce large amounts of airflow with positive and negative charges to neutralize the charges on the objects. Negative or positive charges on the object surface will attract opposite charges in the air, so that the static electricity on the object surfaces will be neutralized and eliminated.
HOYATO-301A Generation 4.5 mechanical and intelligent ionizing air gun is applied in electronic, LED photoelectric,printing, packaging, painting production line, etc.
| Operating voltage | 220V/50Hz or 110V/60Hz |
| Output voltage | AC 4.6KV |
| Operating distance | 100－400mm |
| Ion balance | ≤|±35V| |
| Decay time | ≤2S |
| Operating temperature | 0℃-50℃ |
| Operating humidity | ＜70% |
| Audible noise | ＜70dB |
| Net weight | About 0.5kg(Contain 3M high-tension line) |
| Rough weight | About 1.1kg |
| Working medium | Clean compressed air |
| Air supply connector | Ф8mm |
| Surface | Spray paint |
| Canning material | Composite insulation plastic material |
| External size | 184mm(L)*36mm(W)*185mm(H) |
| Length of high-tension line | 3M |
| Pressure of compressed air | 40-70psi |
| Testing condition | |||
| Humidity:≤60% Testing voltage:1KV-100V Temperature:22℃ | |||
| Distance | 300mm | 600mm | |
| Decay time | Positive | s | s |
| Negative | s | s | |
| Offset voltage | Positive | v | v |
| Negative | v | v | |
