MEGA 32V Series Automotive Bolted Blade Type Fuse High Current Circuit Protection
MEGA 32V Series Automotive Bolted Blade Type Fuse High Current Circuit Protection
Interrupting Rating: 2000A @ 32 VDC
Voltage Rating: 32 VDC
Operating Temperature Range: -40˚C to + 125˚C
Housing Material: PPA-GF33HS
Clear Top Housing Material: PES (top) PPA-GF33HS (bottom)
Terminals: Copper (Silver plated copper available) M6 or M8 bolts available
Mounting Torque: 8-14 Nm M6 12-18 Nm M8
Complies with: ISO 8820-5
| % of Rating | Opening Time Min / Max (s) | |
| 40-250 | 300-500 | |
| 75 | – / – | 14400s / – |
| 100 | 14400s / – | – / – |
| 135 | 120 s / 1800 s | – / – |
| 200 | 1 s / 15 s | 1 s / 15 s |
| 350 | 0.300 s / 5 s | 0.500 s / 5 s |
| 600 | 0.100 s / 1 s | 0.100 s / 1 s |
| Part Number |
Current Rating (A) |
Typ. Voltage Drop (mV) |
Cold Resistance (mΩ) |
I2t (A2 s) |
| 0298040 | 40 | 132 | 2.510 | 8700 |
| 0298060 | 60 | 119 | 1.504 | 21000 |
| 0298080 | 80 | 87 | 0.720 | 21500 |
| 0298100 | 100 | 87 | 0.562 | 31100 |
| 0298125 | 125 | 80 | 0.423 | 57800 |
| 0298150 | 150 | 92 | 0.352 | 100000 |
| 0298175 | 175 | 86 | 0.294 | 168000 |
| 0298200 | 200 | 83 | 0.257 | 204000 |
| 0298225 | 225 | 82 | 0.222 | 257000 |
| 0298250 | 250 | 82 | 0.201 | 389000 |
| 0298300 | 300 | 74 ** | 0.167 | 315000 |
| 0298350 | 350 | 68 ** | 0.138 | 500000 |
| 0298400 | 400 | 64 ** | 0.126 | 610000 |
| 0298450 | 450 | 60 ** | 0.112 | 1050000 |
| 0298500 | 500 | 58 ** | 0.092 | 2050000 |
Q: What can i do if i got a broken product form A-TEAM FUSE INC?
A: First of all please tell us as soon as possible after we will send a new one to you immediately
but please send the broken product to us .you don't have to worry about the carriage charge we will
pay for that.
Q;Are we a importer or manufacturer?
A;We are a manufacturer
Q:Why you have to choose us
A:High quality assurance. The most competitive price and fast shipping
Please tell me:
What product specifications do you need? when you ask for a quotation.I will give you the most
competitive price per as your requirements. And we have many types for you to choose.
P.S.:If you can't find any products to meet your requirements. welcome to send us the details
drawings so that we can provide us our professional & best service to you.
