MEGA 2000 Amp 32 Volt Series Automotive Blade Fuses Automotive Bolted Fuse
MEGA 2000 Amp 32 Volt Series Automotive Blade Fuses , Automotive Bolted Fuse
Interrupting Rating: 2000A @ 32 VDC
Voltage Rating: 32 VDC
Operating Temperature Range: -40˚C to + 125˚C
Housing Material: PPA-GF33HS
Terminals: Copper (Silver plated copper available) M8 bolts
Mounting Torque: 12-18 Nm M8
| % of Rating | Opening Time Min / Max (s) | |
| 125 | 150-275 | |
| 100 | 4 hrs / – | 4 hrs / – |
| 135 | 120 s / 1800 s | 120 s / 1800 s |
| 200 | 1 s / 50 s | 1 s / 150 s |
| 350 | 0.300 s / 5 s | 0.300 s / 5 s |
| 600 | 0.100 s / 1 s | 0.100 s / 1 s |
| Part Number | Current Rating | Typ. Voltage Drop | Cold Resistance | I2t |
| 0298125 | 125 | 67 | 0.330 | 57000 A |
| 0298150 | 150 | 62 | 0.258 | 59000 A |
| 0298175 | 175 | 65 | 0.232 | 123000 A |
| 0298200 | 200 | 61 | 0.214 | 140000 A |
| 0298225 | 225 | 57 | 0.177 | 317000 A |
| 0298250 | 250 | 54 | 0.144 | 637000 A |
| 0298275 | 275 | 53 | 0.122 | 800000 A |
