485 Series 600V Surface Mount Fuse Small SMD High Energy Equipment Circuit Protection
485 Series 600V Surface Mount Fuse Small SMD High Energy Equipment Circuit Protection
The 485 Fuse Series is a small, fast-acting, surface mount ceramic fuse rated at a remarkable 600VDC at its small size and with 100A breaking capacity. It is primarily designed for circuit protection in high energy applications. This product is fully compatible with lead-free solder alloys and higher temperature profiles associated with lead-free assembly.
Features
• Fast-Acting / Surface mount high fuse for voltage (up to 600VDC) applications.
• Fully compatible with lead-free solder alloys and higher temperature profiles associated with lead-free assembly.
• Relatively high breaking capacity at 100A.
• RoHS compliant / Halogen Free • Rating – 1 - 3.15 Amperes.
Applications
• PC server and Telecom systems • LCD TV inverter boards DC input protection • Uninterruptible Power Supply (UPS) / 3-Phase Power Supplies • 380VDC server / lighting in data center
| % of Ampere Rating | Opening Time |
| 100% | 4 hours, Minimum |
| 200% | 60 seconds, Maximum |
| Ampere Rating | Amp Code | Max Voltage Rating | Interrupting Rating | Nominal Cold Resistance | Nominal Melting I2t |
| 1.00 | 001. | 600 | 100A@600VDC, 100A@250VAC | 0.264 | 0.3044 |
| 1.50 | 01.5 | 600 | 0.123 | 0.3917 | |
| 2.00 | 002. | 600 | 0.0744 | 0.8962 | |
| 2.50 | 02.5 | 600 | 0.0583 | 1.4921 | |
| 3.15 | 3.15 | 600 | 0.0395 | 3.304 |
1.What is your MOQ?
A: We provide you small MOQ for each item, it depends your specific order.
2.What is your delivery date?
A: The delivery date is about 2-7days after receipt of payment.
3.What is your payment terms?
A: We accept T/T, western union, ,70% deposit in advance and 30% balance before
shipment.
4.Can you send free samples?
A: Yes, free samples are available; you just need to pay the express fee. You can provide your
a/c like DHL, or you can call your courier to pick up from our office.
5.How do you carry out quality control?
A: Quality is our priority. Our QC always attach great importance to quality control from the
very beginning to the end.
6.Can you accept OEM orders?
A: Yes, we accept OEM & ODM orders, welcome all types of customized orders and cooperation.
Please tell me:
What product specifications do you need? when you ask for a quotation.I will give you the most
competitive price per as your requirements. And we have many types for you to choose.
P.S.:If you can't find any products to meet your requirements. welcome to send us the details
drawings so that we can provide us our professional & best service to you.
