Electronic Circuit Board Very Fast Acting Ceramic Fuse 438 Series - 0603 High Temperature
Electronic Circuit Board Very Fast Acting Ceramic Fuse 438 Series - 0603 High Temperature
The 438 Series is a 100% Lead-free, RoHS compliant and Halogen-free fuse series designed specifically to provide over-current protection to circuits that operate under high working ambient temperature up to 150ºC. The general design ensures excellent temperature stability and performance reliability. The high I²t values which is typical in the Littelfuse Ceramic Fuse family ensure high inrush current withstand capability.
Features
• Operating Temperature from -55ºC to +150ºC
• 100% Lead-free, RoHS compliant and Halogenfree
• Suitable for both leaded and lead-free reflow / wave soldering
Applications
Handheld Electronics • LCD Displays • Battery Packs • Hard Disk Drives • SD Memory Cards
| % of Ampere Rating | Ampere Rating | Opening Time |
| 100% | 0.250A – 6A | 4 hours, Minimum |
| 250% | 0.250A – 6A | 5 Seconds, Maximum |
| Ampere Rating | Amp Code | Max.Voltage | Interrupting Rating | Nominal Resistance | Nominal Melting I2t | Nominal Voltage Drop At Rated | Nominal Power Dissipation At Rated Current |
| 0.25 | 0.25 | 63VDC | 50A @ 63VDC 50A @ 32VAC |
2.218 | 0.0017 | 0.55 | 0.138 |
| 0.375 | 0.375 | 63VDC | 1.247 | 0.0041 | 0.488 | 0.183 | |
| 0.5 | 0.5 | 63VDC | 0.829 | 0.01 | 0.486 | 0.243 | |
| 0.75 | 0.75 | 63VDC | 0.466 | 0.0281 | 0.378 | 0.284 | |
| 1 | 1 | 63VDC | 0.31 | 0.0593 | 0.351 | 0.351 | |
| 1.25 | 1.25 | 63VDC | 0.2 | 0.051 | 0.365 | 0.456 | |
| 1.5 | 1.5 | 63VDC | 0.174 | 0.0902 | 0.368 | 0.552 | |
| 1.75 | 1.75 | 63VDC | 1.405 | 0.144 | 0.36 | 0.54 | |
| 2 | 2 | 32 | 50A @ 32VDC/12VAC | 0.051 | 0.149 | 0.107 | 0.214 |
| 2.5 | 2.5 | 32 | 0.0324 | 0.1977 | 0.095 | 0.238 | |
| 3 | 3 | 32 | 0.0255 | 0.2922 | 0.093 | 0.279 | |
| 3.5 | 3.5 | 32 | 0.0205 | 0.4752 | 0.082 | 0.287 | |
| 4 | 4 | 32 | 0.017 | 0.692 | 0.079 | 0.316 | |
| 5 | 5 | 32 | 0.0115 | 0.7398 | 0.074 | 0.37 | |
| 6 | 6 | 24 | 50A @ 24VDC/12VAC | 0.0085 | 1.3838 | 0.072 | 0.432 |
