62mA - 15A 0251 Series Fast Acting Ceramic Fuse With 32V - 125V Voltage
62mA - 15A 0251 Series Fast Acting Ceramic Fuse With 32V - 125V Voltage
The Very Fast-Acting Fuse is designed to meet an extensive array of performance characteristics in a space-saving subminiature package.
Features
• Very fast-acting
• Small size
• Wide current rating range (62mA- 15A)
• Halogen-free available
• Wide operating temperature range
• Low temperature rerating
Applications
• Flat–panel display TV
• LCD monitor
• LCD backlight inverter
• Office machines
• Power supply
• Audio/Video system
• Lighting system
• Medical equipment
| % of Ampere Rating | Ampere Rating | Opening Time |
| 100% | 62mA - 15A | 4 Hours, Min. |
| 200% | 62mA - 7A | 1 Second, Max. |
| 10A | 3 Seconds, Max. | |
| 12 - 15A | 10 Seconds, Max. | |
| 275% | 500mA, 1A, 2A, 2.5A, 3A, 4A, 5A, 7A, 10A | 300 msecs., Max |
| 400% | 500mA, 1A, 2A, 2.5A, 3A, 4A, 5A, 7A, 10A | 30 msecs., Max. |
| 1000% | 500mA, 1A, 2A, 2.5A, 3A, 4A, 5A, 7A, 10A | 4 msecs., Max. |
| Ampere Ratingng (A) | Amp Codede | Ordering Number ber (Std.) | Ordering Number umber (Mil.) | iMax Voltage Rating ng (V) | Interrupting Ratingupting Rating | Nominal CoNominal Cold Resistance Resistance (Ohms) | Nominal Melting g I 2t (A2 sec) | Nom rNom Voltage Dropop (V) |
|
.062
|
.062
|
251.062
|
253.062
|
125
|
300 A @ 125VDC 50 A @ 125VAC For CCC 7A: 70A @ 125VAC For CCC 10A: 100 A @ 125VAC |
7.000
|
0.000113
|
1.4
|
|
.125
|
.125
|
251.125
|
253.125
|
125
|
1.700
|
0.00174
|
0.285
|
|
|
.200
|
.200
|
251.200
|
253.200
|
125
|
1.011
|
0.0048
|
0.345
|
|
|
.250
|
.250
|
251.250
|
253.250
|
125
|
0.665
|
0.0116
|
0.24
|
|
|
.375
|
.375
|
251.375
|
253.375
|
125
|
0.395
|
0.0296
|
0.215
|
|
|
.500
|
.500
|
251.500
|
253.500
|
125
|
0.280
|
0.0598
|
0.2165
|
|
|
.630
|
.630
|
251.630
|
|
125
|
0.205
|
0.094
|
0.188
|
|
|
.750
|
.750
|
251.750
|
253.750
|
125
|
0.175
|
0.153
|
0.176
|
|
|
1.00
|
001.
|
251001.
|
253001.
|
125
|
0.128
|
0.256
|
0.194
|
|
|
1.25
|
1.25
|
2511.25
|
|
125
|
0.100
|
0.390
|
0.2
|
|
|
1.50
|
01.5
|
25101.5
|
25301.5
|
125
|
0.0823
|
0.587
|
0.21
|
|
|
2.00
|
002.
|
251002.
|
253002.
|
125
|
0.0473
|
0.405
|
0.141
|
|
|
2.50
|
02.5
|
25102.5
|
|
125
|
0.0360
|
0.721
|
0.132
|
|
|
3.00
|
003.
|
251003.
|
253003.
|
125
|
0.0290
|
1.19
|
0.131
|
|
|
3.50
|
03.5
|
25103.5
|
|
125
|
0.0240
|
1.58
|
0.1205
|
|
|
4.00
|
004.
|
251004.
|
253004.
|
125
|
0.0204
|
2.45
|
0.114
|
|
|
5.00
|
005.
|
251005.
|
253005.
|
125
|
0.0155
|
4.14
|
0.11
|
|
|
7.00
|
007.
|
251007.
|
253007.
|
125
|
0.0105
|
10.4
|
0.102
|
|
|
10.0
|
010.
|
251010.
|
253010.
|
125
|
0.00705
|
25.5
|
0.1
|
|
|
12.0
|
012
|
251012.
|
|
32
|
300A@32VDC &50A@32VAC
|
0.0055
|
45.2
|
0.0878
|
|
15.0
|
015.
|
251015.
|
253015.
|
32
|
0.00446
|
68.8
|
0.071
|
