TH35-7.5 DIN35 Rail Installation 30A 600V DC Midget Fuses 10x38mm
30A 600V Use Midget Fuses ( 10 * 38 ) Use 75°C Cu Wier Only
|
Type
|
SRD-30
|
|
|
Fuse size
|
10 x 38MM
|
14X85MM
|
|
Poles
|
1P
|
|
|
Rated voltage
|
DC 1000V
|
DC 1500V
|
|
Rated current
|
1,2,3,4,5,6,8,10,12,15,20,25,30A
|
1-63A
|
|
Short-circuit breaking capacity
|
33KA
|
20KA
|
|
Max power attenuation
|
3.5W
|
6.5W
|
|
Connection
|
2.5-10mm2
|
1-16mm2
|
|
Operation ambient temperature
|
-40℃-﹢90℃
|
-30~+70°C
|
|
Resistance and damp hot
|
Class 2
|
|
|
Elevation
|
≤ 2000
|
|
|
Installation way
|
TH35-7.5/DIN35 Rail installation
|
|
|
