Family House Roof Outdoor Fire Safety Switch With Solar Power Generation

Switch Solar Power Station Family House Factory Roof Outdoor Solar Power Generation Firefighters Fire

How to achieve rapid Shutdown (RSD)?

The quick shutdown function requires two devices -- a transmitter and receivers.

The transmitter is responsible for transmitting the quick shutdown power line signal to the DC wire between the PHOTOVOLTAIC module array and the inverter, and the receiver is responsible for detecting the signal on these conductors:

§ When the signal exists, the receiver remains inactive and the components work normally;

§ When the signal disappears, the receiver is responsible for lowering the pv module array voltage below the standard limit voltage within a specified period of time, thus realizing the fast shutdown function.

Pefs-el Group cascade fire safety switch for PV 6~10 series (Commercial/power station grade)

Product highlights:

Shut off 6-10 strings of components

Maximum loop current 55A

Maximum loop voltage 1500Vdc

CE standard

Sheet metal housing, IP65 protection grade

Multiple interface types available (Gran /MC4 terminal)

Disconnecting switch complies with TUV, CE, CB, SAA, UL certification

Equipped with a waterproof air vent valve to avoid condensation inside the shell

Real-time detection of the highest environmental temperature inside the shell, when the internal temperature exceeds 70℃, automatic switch off

Applicable to industrial and commercial, ground power stations and other photovoltaic systems
