Intelligent Tripod Turnstile Gate 220V Office Security Gates
Product description for TCPIP And RFID Support Tripod Turnstile For University Dormitory
| Technical Data | Unit | EL128 |
| Passage width | mm | <550 |
| Throughput rate | p/m | 35 |
| Power supply | V(ac) | 100-240 |
| Operational voltage | V(dc) | 24 |
| Max power consumption | w | 30 |
| Frequency | hz | 50-60 |
| prectection level | ip | >44 |
| Working temperature | degree | -25 to +70 |
| Dimension excluding bars | mm | 480X280X955 |
| Net weight including bars | Kg | 33 |
Features and Benefits
1. Passage direction: the free setting of uni-direction or bi-direction to control access, and uni-directional free passage, bi-directional free passage or uni-directional card swiping passage or bi-directional card swiping passage are allowed.
2. Turnstile rod reset: the turnstile rod will automatically reset to its original position after pedestrians pass through.
3. Memory function: continuous swiping card allows corresponding person to pass, and this is suitable for special occasions.
4. Passage reset: the turnstile will automatically close in case of no one entry within limiting time after swiping card, and the limiting time is adjustable.
Communication
• Dry contact relay with 12 volt or 24 volt pulse
• Rs485, or Tcp-lp communication with computer
