Steel Construction Materials HDG Round Dowels Bar 500mm Length Q345B
Price:
Negotiable
MOQ:
100pcs
Delivery Time:
7-10days
Brand:
Qijie
Product Description
Steel Construction Materials HDG Round Dowels Bar
Product Description
Steel construction materials HDG round dowels bar
Description
Structural grade round dowels are friction cut to length, not cropped. They are available in a variety of standard, off-the-shelf sizes.
Round dowels are manufactured from AS/NZS 3679.1 compliant Grade 300 steel, and are hot-dipped galvanised to AS/NZS 4680.
Features:
Description
Structural grade round dowels are friction cut to length, not cropped. They are available in a variety of standard, off-the-shelf sizes.
Round dowels are manufactured from AS/NZS 3679.1 compliant Grade 300 steel, and are hot-dipped galvanised to AS/NZS 4680.
Features:
- Dowels manufactured from AS/NZS 3679.1, Grade 300 steel.
- Hot dipped galvanised to AS/NZS 4680 as standard.
- Fiction cut dowels, not cropped.
- Custom lengths available upon request. Minimum order quantites will apply.
Specification:
| Hot-dip galvanised Dowels: | ||||
| Product | Shape | Diameter / Size | Length | Recommended Sleeve |
| [mm] | [mm] | |||
| DBHDG12Rx300mm | Round | 12 | 300 | EXJDS12Rx150 |
| DBHDG16Rx450mm | Round | 16 | 450 | UDS16Rx230 |
| DBHDG16Rx600mm | Round | 16 | 600 | UDS16Rx300 |
| DBHDG20Rx450mm | Round | 20 | 450 | UDS20Rx230 |
| DBHDG20Rx600mm | Round | 20 | 600 | UDS20Rx300 |
| DBHDG24Rx450mm | Round | 24 | 450 | UDS24Rx225 |
| DBHDG33Rx450mm | Round | 33 | 450 | UDS33Rx230 |
| DBHDG33Rx600mm | Round | 33 | 600 | UDS33Rx300 |
| DBHDG36Rx450mm | Round | 36 | 450 | UDS36Rx230 |
| DBHDG36Rx600mm | Round | 36 | 600 | UDS36Rx300 |
| DBHDG16SQx450mm | Square | 16 x 16 | 450 | UDS16Sx230 |
| DBHDG16SQx600mm | Square | 16 x 16 | 600 | UDS16Sx300 |
| DBHDG20SQx450mm | Square | 20 x 20 | 450 | UDS20Sx230 |
| DBHDG20SQx600mm | Square | 20 x 20 | 600 | UDS20Sx300 |
| Mill finished Dowels: | ||||
| Product | Shape | Diameter / Size | Length | Recommended Sleeve |
| [mm] | [mm] | |||
| DB12Rx300mm | Round | 12 | 300 | EXJDS12Rx150 |
| DB16Rx450mm | Round | 16 | 450 | UDS16Rx230 |
| DB16Rx600mm | Round | 16 | 600 | UDS16Rx300 |
| DB20Rx450mm | Round | 20 | 450 | UDS20Rx230 |
| DB20Rx600mm | Round | 20 | 600 | UDS20Rx300 |
| DB24Rx450mm | Round | 24 | 450 | UDS24Rx225 |
| DB33Rx450mm | Round | 33 | 450 | UDS33Rx230 |
| DB33Rx600mm | Round | 33 | 600 | UDS33Rx300 |
| DB36Rx450mm | Round | 36 | 450 | UDS36Rx230 |
| DB36Rx600mm | Round | 36 | 600 | UDS36Rx300 |
| DB16SQx450mm | Square | 16 x 16 | 450 | UDS16Sx230 |
| DB16SQx600mm | Square | 16 x 16 | 600 | UDS16Sx300 |
| DB20SQx450mm | Square | 20 x 20 | 450 | UDS20Sx230 |
| DB20SQx600mm | Square | 20 x 20 | 600 | UDS20Sx300 |
Steel Dowel Bars Specification :
Standard : ASTM A615, ASTM A1078, ASTM A775, BS4449, AASHTO M254
Epoxy Coating Standard : ASTM A775 / A775M
Ends : Chamfering & Plain
Grade : ASTM A615 Grade 60, Grade 250
Length : 100mm to 6000mm
| Mild Carbon Steel Dowel Bar | |||||
| Product | Coating | Steel Grade | Coated Standard | Diameter (mm) | Diameter (inches) |
| Dowel Bar | Black(uncoated) | BS4449-grade250, ASTM A615/A615M, A615 Gr60, Gr40, Grade500N, Q235B, SS400, S275JR, etc | AISI, ASTM, BS, DIN, GB, JIS | 16 ~ 50 | 5/8″~ 2″ |
| Epoxy coated dowel bar | Epoxy coated | ASTM A1078 | 16 ~ 50 | 5/8“~ 2“ | |
| Galvanized dowel bar | Galvanized | BS EN ISO 1461:2009; AS/NZS 4680 | 16 ~ 50 | 5/8“~ 2“ |
|
