Security Bto-22 Blade Stainless Protective Welded Steel Razor Barbed Wire Mesh Roll
Razor Barbed Wire is also named concertina razor wire, razor fencing wire, razor blade wire or dannert wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Razor Type
|
Notes
|
|
450mm
|
33
|
7M-8M
|
CBT-60, 65
|
Single Coil
|
|
500mm
|
56
|
12M-13M
|
CBT-60, 65
|
Single Coil
|
|
700mm
|
56
|
13M-14M
|
CBT-60, 65
|
Single Coil
|
|
960mm
|
56
|
14M-15M
|
CBT-60, 65
|
Single Coil
|
|
450mm
|
56
|
8M-9M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
500mm
|
56
|
9M-10M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
10M-11M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
8M-10M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
700mm
|
56
|
10M-12M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
800mm
|
56
|
11M-13M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
900mm
|
56
|
12M-14M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
960mm
|
56
|
13M-15M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
980mm
|
56
|
14M-16M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
Application of concertina razor barbed wire
Razor Barbed Wire is widely used in airport , prison, government, bank, and also in living wall, personal house, villatic wall, window, autobahn, railway and border of the fence.
Packing of concertina razor barbed wire
compression rolls, water-proof paper inside, woven bag outside or in carton
Weave characteristics of concertina razor barbed wire
twist and weave, fastness ,beautiful; galvanizing after weaving, galvanizing before weaving. It is divided to electrical galvanized ,hot - dipped galvanized, plas-tic coating, stainless steel, etc.
Advantages of concertina razor barbed wire
Razor barbed wire mesh is a new kind of protective fencing with such advantages as beautiful appearance,economical cost and practicality.
The razor wire can welded to mesh panel with a frame as the fence installed on the prison wall, the hole shape can be rectangle and diamond.
1>Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
2>Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.
| Hole shape | Mesh width | Suited blade specifications |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
