8 ft x 50 ft Chain Link Security Fence with Razor Barbed Wire for High Level Security

Chain link security fence is also called security grade chain link fencing system.Combined with barbed wire and razor wire,it is designed to increase the difficulty to climb and penetrate, which provides greater levels of security for protecting personal safety and property.The fence can be used as galvanized chain link fabric, PVC coated iron chain wire fence and stainless steel chain link fence. Heavy type chain-link fences with barbed wire or razor wire fence together can supply high strength used for prison security.

1. Fabric: Heavy Galvanized Chain Link Fabric made from Galvanized steel wire, 3.76 mm diameter, mesh size 50 × 50 mm, fabric height 2.40 m barbed selvage, supplied in rolls of 15 m each.
2. Tension Wire: Heavy Galvanized 3.76 mm diameter, sufficient for 3 rows.
3. Barbed Wire: Galvanized barbed wire, 2 Ply, 4 Points. Galvanized strand wire 2.50 mm diameter, Galvanized barb wire 2.0 mm diameter, spacing between barbs 101 mm, supplied in reels of 200 m, sufficient for 6 rows.
4. Line Posts: 60.3 mm od × 3.91 mm wall thickness × 3.20 meter long Galvanized steel post with Galvanized 'V' shaped extension arm on top to take 6 rows of barbed wire, spacing at 3.0 m intervals.
5. Pull Post: 73.0 mm od × 5.16 mm wall thickness × 3.20 m long Galvanized post with 42.2 mm od × 3.56 mm wall thickness × 6.0 m long Galvanized steel brace rail pipe, Galvanized 'V' shaped extension arm to take 6 rows of barbed wire. Pull Post supplied with standard Galvanized straining fittings like truss rod, turn buckle, tension bar, bands, spacing at 152 m intervals.
6. Corner Post: Same as item no. 5 above, but with corner extension arm.
7. End Post: Same as item no. 5 above, but with only half the fittings.
8. Bottom Rail: 42.2 mm od × 3.56 mm wall thickness × 6.0 m long Galvanized steel Bottom Rail Pipe with galvanized steel clamps to connect the pipes together.

Table 1 – Zinc Coated Wire Characteristics

Table 2 – Zinc Coated Chain Link Mesh Selection

Table 3 – Chain Link Fence Post Selection

Application
