304 Stainless Steel Screen Mesh, PVC Coated Black/ Powder Coated Black

powder coated or epoxy coated 304 and 316 stainless steel meshes for insect screening products. This type of s.s. mesh screen is mostly in the treatment of PVC coating or black powder coating finish. Also known as black powder coated Stainless Steel Mesh Insect Screen. With firm and flat coated surface, the wire mesh screen offers good ventilation and excellent strength, suitable for keeping flies and mosquitoes out of windows and doors.

The powder coated stainless screen can be divided into two types according to basic mesh materials: Powder coated 304 mesh screen and Black Powder Coated 316 series insect screen. We also supply non-powder coating stainless steel window screen with natural finishes.

304 Stainless steel Screen Mesh, PVC coated black/ Powder Coated Black
Specifications

Mesh Size/ Count Mesh - Wire Diameter
18 x 16 - 0.26 mm
20 x 20 - 0.25 mm
16 x 16 - 0.24 mm

Open Area – Around 70%.

Roll Size/Width - 3',4', 5’.

Black Powder Coated 316 and 316L Security Mesh for Window Screen

Materia: 304,316,316L ,T316 etc stainless steel wire

Surface treatment: Epoxy or PVC powder coating. Color can be black ,white ,grey

Weave type: Plain weave

Wire diameter: 0.6mm,0.7mm,0.8mm,0.9mm

Mesh size: 10-14 mesh

Common size: 0.6mm-14 mesh , 0.7mm-12 mesh, 0.8mm-11 mesh , 0.9mm-10 mesh

Wire mesh roll size: 750x2000mm, 900x2000mm,1200x2000mm,750x2400mm, 900x2400mm,1200x2400mm

Applications: Widely used on doors and windows for protect also prevent insects and flies.

Hehua also supplies stainless steel natural finish wire mesh for window screening uses, without any powder coating.

304 Stainless Steel Mesh Window Screen Natural Finish with No Powder Coating

Specifications

Mesh Size/ Count Mesh - Wire Diameter
18 x 16 - 0.27mm
14 x 14 -0.35 mm

Benefits and Features:

• Excellent resistance to corrosion and impact.
• Quality meets the demands of GB/T 1220–2007 Stainless Steel Rod standard grade.
• Good privacy protection and aesthetic effect.
• Easy to install with flat and straight surface.
• Good air circulation & high quality daylighting.
