18 Gauge 4 Point 2 Strand Galvanized Barbed Wire Coils 20kg Coil

Price Negotiable
Price: Negotiable
MOQ: 100pcs
Delivery Time: 8-15days
Brand: barbed wire
Product Description



18 Gauge 4 Point 2 Strand Galvanized Barbed Wire 20kg Coil



Barbed wire, also known as barb wire (and sometimes bob-wire or bobbed wire), is a type of fencing wire constructed with sharp edges or points arranged at intervals along the strand(s). It is used to construct inexpensive fences and is used at top.walls surrounding secured property.

Currently, Double Twist Barbed Wire been widely used by many countries in military field, prisons, detention houses, government buildings and other national security facilities. Recently years, barbed tape has apparently become the most popular high-class fencing wire for not only military and national security applications, but also for cottage and society fence, and other private buildings.

Barbed Wire Materials:

Material: high-quality low carbon steel wire, stainless steel wire, medium carbon steel wire(galvanized, plastic coated, plastic sprayed)

Assortment:

Electro-galvanized Barbed Wire,

Hot Dipped Barbed Wire and

PVC Barbed Wire

Barbed wire weave types:

1) single strand barbed wire,

2) double-strand reverse twisted barbed wire;

3) double-strand common twisted barbed wire

Barbed Wire

Common Gauge of Strand and Barb:
1.8X1.8mm / 2.0X2.0mm / 2.2X2.0mm / 2.2X2.2mm / 2.5X2.0mm / 2.5X2.2mm / 2.6X2.2mm / 2.7X2.2mm / 2.8X2.2mm /
3.0X2.0mm.
Barb Spacing: 3''-6'.
Barbed Wire Roll Length:200m/250m/400m/500m/600m.

Characteristic: firm and beautiful.

Barbed Wire Uses:

Barbed wire can be widely used as accessories for woven wires fences to form a fencing system or security system. barbed wire is suitable for industry, agriculture,

animal husbandry, dwelling house, plantation or fencing.

It is called barbed wire fences or barbed obstacles when it is used simply by itself along the wall or the building to give a kind of protection.

Advantages: Because of its convenient delivery, easy installment and unique modal, enable it can bring wonderful protective effects.

Specification of barbed wire
Type Wire gauge(SWG)

Barb distance

(cm)

Barb length

(cm)

Electric/Hot-dip

galvanized barbed wire

10# x 12#

7.5-15

(3”-6”)

1.5-3
12# x 12#
12# x 14#
14# x 14#
14# x 16#
16# x 16#
16# x 18#

PVC coated/PE

barbed wire

Before coating After coating

7.5-15

(3”-6”)

1.5-3
1.0mm-3.5mm 1.4mm-4.0mm
BWG11#-20# BWG8#-17#
SWG11#-20# SWG8#-17#


PVC PE coating thickness:0.4mm-0.6mm;

different colors or length are available at customer’s request





Wire gauge

Weight 10kgs

per coil

Weight 15kgs

per coil

Weight 25kgs

per coil

1X20FCL Length 1X20FCL Length 1X20FCL Length
16#X16# 15TONS 160M 15TONS 240M 16TONS 400M
16#X14# 16TONS 125M 16TONS 180M 17TONS 300M
14#X14# 17TONS 100M 17TONS 150M 18TONS 250M
14#X12# 18TONS 80M 18TONS 120M 19TONS 200M
12#X12# 19TONS 65M 19TONS 100M 20TONS 160M

The others can make according to custmoers request.



Barbed Wire

Barbed Wire
