Factory Sale 304 Stainless Steel Wire Rope Mesh Woven Stainless Steel Rope Mesh For Zoo Mesh
Factory Sale 304 Stainless Steel Wire Rope Mesh Woven Stainless Steel Rope Mesh For Zoo Mesh
1.Material:stainless steel wire (304,304L,316,316L etc)
2.Rope dia.:1.0mm-4.0mm
3.Popular Mesh Size: 1"*1", 1-1/2"*1-1/2",2"*2",3"*3",4"*4"
4.Structure:7x7 and 7x19 etc.
5.Fatigue resistance, impact resistance, breaking force, the overall structure of the rugged life of more than 30 years;
6.Boycott of the masticatory rodents and other pests (tensile strength of about 100-110000 PSI), good flexibility, won't hurt plumage or animal skin contact
7.Features: light weight, high strength, never rust, good softness, high fatigue strength, high impact resistance, large crushing force,
8.Application: animal zoo, building
steel wire rope mesh roll
9.Main Specifications:
| stainless steel wire rope mesh-zoo mesh specifications | ||||
| NO | structure | breaking force ( KN ) | wire diameter(MM) | opening (MM) |
| RX32115 | 7 X 19 | 7.38 | 3.2 | 115 X 115 |
| RX3290 | 7 x 19 | 7.38 | 3.2 | 90 x 90 |
| RX24102 | 7 x 7 | 4.18 | 2.4 | 102 x 102 |
| RX2490 | 7 x 7 | 4.18 | 2.4 | 90 x 90 |
| RX2476 | 7 x 7 | 4.18 | 2.4 | 76 x 76 |
| RX2451 | 7 x 7 | 4.18 | 2.4 | 51 x 51 |
| RX2078 | 7 x 7 | 3.17 | 2 | 78 x 78 |
| RX2066 | 7 x 7 | 3.17 | 2 | 66 x 66 |
| RX2051 | 7 x 7 | 3.17 | 2 | 51 x 51 |
| RX2038 | 7 x 7 | 3.17 | 2 | 38 x 38 |
| RX1676 | 7 x 7 | 2.17 | 1.6 | 76 x 76 |
| RX1651 | 7 x 7 | 2.17 | 1.6 | 51 x 51 |
| RX1638 | 7 x 7 | 2.17 | 1.6 | 38 x 38 |
| RX1531 | 7 x 7 | 2 | 1.5 | 31x 31 |
