Welded Wire Mesh Steel Farm Gates Strong Low Carbon Steel Material
Design Open Power Coated Steel Welded Wire Mesh Farm Gate To Australian Standard
Whites Rural "N" Stay Farm Gates offer increased strength with a diagonal support brace running from the bottom to top corner.
Consistently high-quality gates manufactured from high quality galvanised pipe. The pipe is galvanised on the inside as well as the outside to provide maximum protection and a long working life.
Production Flow
|
1. Style |
N stay/brace farm gate |
|
2. Material |
Hot dipped galvanized steel pipe and wire |
|
3. Manufacturing process: |
(1)Wire mesh panel welding and corner wire cutting Pipe cut, flattend and wave; (2)Pipe frame welding; |
Applications
Widely used in the farm/ranch for enclosure of livestock/animal(sheep/goats/cattle/horse etc) or protecting
crops/vegetable. It also can be used as barrier fencing in car park area, or store fence.
Specification
|
Farm Gate |
|
| 1. Wire diameter | 5mm |
| 2. Mesh opening | 100*200mm |
| 3. Frame pipe | 32mm*2mm |
| 4. Height | 1170mm |
| 5. Length( Feet) | 6', 8', 10', 12', 14', 16' |
| 6. Length( mm) | 900mm, 2400mm, 3000mm, 3600mm, 4200mm, 4800mm |
|
N stay/brace farm gate |
|||
|
Nominal (mm & ft) |
Actual (mm) |
Weight (Kg) |
Weld Mesh Nom. (mm) |
|
3000 (10’0”) |
3000 |
24 |
200x100x5 |
|
3600 (12’0”) |
3610 |
28 |
200x100x5 |
|
4200 (14’0”) |
4220 |
32 |
200x100x5 |
|
4800 (16’0”) |
4830 |
36 |
200x100x5 |
