Eye Pleasing Cost Of Livestock Cattle Yard Panels Farm Fences
Eye Pleasing Cost Of Livestock Cattle Yard Panels Farm Fences
Design 1: Oval rail with square vertical tube
| Design 1 | Oval rail with square vertical tube |
| Height | 1.6m, 1.8m. |
| Width | 2.07m, 2.09m, 2.2m, 2.9m |
| Horizontal oval rail | 30X60mm, 40X80m,42X115mm |
| Rail quantity | 4pcs, 5pcs, 6pcs |
| Vertical square tube | 40x40mm, 50x50mm, 75x75mm |
| Welded parts | U lugs, L lugs, caps, panel base |
| Accessories | Pins |
| Surface treatment | Hot dipped galvanized |
Design 2: All square tubes corral panel
| Design 2 | Rails and vertical post are all square tube |
| Height | 1.8m. |
| Width | 2.07m, 2.09m |
| Horizontal square rail | 40x40mm, 50x50mm |
| Rail quantity | 6pcs |
| Vertical square tube | 40x40mm,50x50mm |
| Welded parts | U lugs, L lugs, caps, panel base |
| Accessories | pins |
| Surface treatment | Hot dipped galvanized |
Design 3: All round tubes corral panel
| Design 3 | Rails and vertical post are all round tube |
| Height | 1.8m. |
| Width | 2.07m |
| Horizontal round tube rail | 42mm or 48mm O.D. |
| Rail quantity | 6pcs |
| Vertical round tube | 42mm or 48mm O.D. |
| Welded parts | U lugs, L lugs, caps, panel base |
| Accessories | pins |
| Surface treatment | Hot dipped galvanized |
Design 4: round tube with bent bottom base
| Design 4 | Round tube with bent bottom base |
| Height | 5ft, 6ft |
| Width | 9ft, 10ft,12ft |
| Frame and rail | 32mm or 42mm O.D. |
| Rail quantity | 6pcs |
| Welded parts | U lugs, L lugs, caps, panel base |
| Accessories | Pins |
| Surface treatment | Hot dipped galvanized or powder coated |
Features
Square vertical pipe/post, welding easy and firm, much durable, and it's more beatiful.
Oval horizontal rails, no sharp edge, can protect animals from getting hurt, high safety, perfect spacing, protect the lambs or calf from running away and breaking legs.
Middle braces for high strength and heavy duty with welded top caps and foot plates, water and dust proof welded "U" and "L" lugs for easy connection. The lugs are welded for all four sides, very durable and safe.
Footplate on the panel, can cement the panels on the ground by pins. 2 joining pins are supplied for each panel.
Application
Cattle panel are widely used in animal husbandry to raising livestock. The connection is very flexible, every panel has lugs so you can connect the panels according to your need.
The galvanized metal rail panels are very suitable for animal stall, feedlot fence, horse corral fence, area fence etc.
