Metal Horse Fence Panel Cattle Yard Panels Cheap Sheep Panel For Sale
Metal Horse Fence Panel Cattle Yard Panels Cheap Sheep Panel For Sale
High Strength Imported Animal Metal Panel For Cattle Shed are available in different heights, widths and bar or rail thickness to suit different requirements. High Strength Imported Animal Metal Panel For Cattle Shed can also be used to create a cattle yard. Just like a fence,High Strength Imported Animal Metal Panel For Cattle Shed can be assembled next to each other to form an enclosure. It is best to purchase steel cattle panels from a steel manufacturer who specialises in cattle panels, to get the right product for your needs.
Round style
| Material | Pre hot dipped galvanized steel pipe |
| Finishing (zinc coating) | More than 15 microns |
| Height x Length | 1800mm x 2100mm |
| Vertical pipe |
32mm O.D x1.6mm thickness 42mm O.D x 1.6 mm thickness |
| Horizontal rails |
32mm O.D x1.6mm thickness 42mm O.D X 1.6mm thickness (6 round rails) |
| Welding | Fully welded post brackets |
| Welds | Bull bars are fully welded, each weld is protected with epoxy paint |
Square tube style
| Material | Pre hot dipped galvanized steel pipe |
| Finishing (zinc coating) | More than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| Vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness |
| Horizontal rails |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness (6 square rails) |
| Welding | Fully welded post brackets |
| Welds | Bull bars are fully welded, each weld is protected with epoxy paint |
Cattle panels is designed for the safe and effective flow of cattle in the lead up to the race, reducing stress on livestock by separating operator and beast.
Cattle panel can have different shapes, below are the popular shapes and specification on the market.
Oval tube style
| Material | Pre hot dipped galvanized steel pipe |
| Finishing (zinc coating) | More than 15 microns |
| HeightxLength | 1800mm x 2100mm |
| Vertical pipe |
50 x 50mm RHS x 1.6mm thickness 40 x 40mm RHS x 1.6mm thickness |
| Horizontal rails |
30x60mm oval rail x 1.6mm thickness 40x80mm oval rail x 1.6mm thickness 40x120mm oval rail x 1.6mm thickness (6 oval rails) |
| Welding | Fully welded post brackets |
| Welds | Bull bars are fully welded, each weld is protected with epoxy paint |
Cattle panel gate
| Height x Length: | 2200mm x 2000mm |
| Frame: | Horizontal & Vertical pipe: 50 mm x 50 mm RHS x 1.8 mm thick with fully welded caps |
| Cattle Gate Horizontal rail: | 40 mm x 80 mm x 1.6mm thick x 6 oval rails |
| Finishing: |
Hot dipped galvanized ,zinc coating:more than 15 microns. Fully welded oval pipes, post &brackets ,heavy duty hinges |
