316l /304 Stainless Steel Woven Wire Mesh 100 Mesh 0.089mm Diameter 0.17mm Aperture
Price:
Negotiable
MOQ:
1 roll of stainless steel wire mesh
Delivery Time:
7 work days
Brand:
HUIHAOKST
Product Description
Stainless steel hardware cloth filter mesh woven stainless steel mesh stainless steel wire cloth
Stainless steel wire mesh is made by stainless steel wire,Due to its own characteristics of stainless steel, the stainless steel mesh processed has high wear resistance, long service life, accurate mesh, uniform structure, no curl, easy to use, uniform screen thickness, anti static, anti-acid and alkali resistance Corrosion.
stainless steel wire mesh types
- Plain weave:
This is the most commonly used weaving type.
Each warp wire crosses alternately above and below each weft wire. Warp and weft wires generally have the same diameter.
Each warp wire crosses alternately above and below each weft wire. Warp and weft wires generally have the same diameter.
|
Mesh/Inch
|
Wire Diameter
|
Aperture
|
Open Area
|
Weight(LB) /100 Square Foot
|
||
|
|
Inch
|
MM
|
Inch
|
MM
|
|
|
|
1x1
|
.080
|
2.03
|
.920
|
23.37
|
84.6
|
41.1
|
|
2X2
|
.063
|
1.60
|
.437
|
11.10
|
76.4
|
51.2
|
|
12X12
|
.020
|
.508
|
.063
|
1.60
|
57.2
|
31.6
|
|
14X14
|
.023
|
.584
|
.048
|
1.22
|
45.2
|
49.8
|
|
30X30
|
.009
|
.229
|
.0243
|
.62
|
53.1
|
16.1
|
|
35X35
|
.011
|
.279
|
.0176
|
.45
|
37.9
|
29.0
|
|
40X40
|
.010
|
.254
|
.0150
|
.38
|
36.0
|
27.6
|
|
80X80
|
.0065
|
.165
|
.0060
|
.15
|
23.0
|
23.2
|
|
100X100
|
.0035
|
.089
|
.0065
|
.17
|
42.3
|
8.3
|
|
110X110
|
.0040
|
.1016
|
.0051
|
.1295
|
30.7
|
12.4
|
|
120X120
|
.0037
|
.0940
|
.0064
|
.1168
|
30.7
|
11.6
|
|
150X150
|
.0026
|
.0660
|
.0041
|
.1041
|
37.4
|
7.1
|
|
160X160
|
.0025
|
.0635
|
.0038
|
.0965
|
36.4
|
5.94
|
|
180X180
|
.0023
|
.0584
|
.0033
|
.0838
|
34.7
|
6.7
|
|
200X200
|
.0021
|
.0533
|
.0029
|
.0737
|
33.6
|
6.2
|
|
250X250
|
.0016
|
.0406
|
.0024
|
.0610
|
36.0
|
4.4
|
|
270X270
|
.0016
|
.0406
|
.0021
|
.0533
|
32.2
|
4.7
|
|
300X300
|
.0051
|
.0381
|
.0018
|
.0457
|
29.7
|
3.04
|
|
325X325
|
.0014
|
.0356
|
.0017
|
.0432
|
30.0
|
4.40
|
|
400X400
|
.0010
|
.0254
|
.0015
|
.370
|
36.0
|
3.3
|
|
500X500
|
.0010
|
.0254
|
.0010
|
.0254
|
25.0
|
3.8
|
|
...
|
...
|
...
|
...
|
...
|
...
|
...
|
- Twill Weave:
The wires of the weft and the warp intercross two above and two below, inverting the intersections of the warp wire at an
established distance and obtaining a rigid, stable and robust type of wire mesh fabric.
established distance and obtaining a rigid, stable and robust type of wire mesh fabric.
Dutch Twilled Weaving:
|
Mesh
|
Wire Diameter (MM)
|
Material (AISI)
|
|
12meshX64mesh
|
0.58/0.40
|
304 or 316
|
|
24meshX110mesh
|
0.36/0.25
|
304 or 316
|
|
14meshX88mesh
|
0.50/0.33
|
304 or 316
|
|
30meshX150mesh
|
0.18/0.14
|
304 or 316
|
|
40meshX200mesh
|
0.14/0.11
|
304 or 316
|
|
50meshX250mesh
|
0.10/0.071
|
304 or 316
|
|
80meshX700mesh
|
0.06/0.05
|
304 or 316
|
|
165meshX800mesh
|
0.071/0.040
|
304 or 316
|
|
165meshX1400mesh
|
0.05/0.032
|
304 or 316
|
|
200meshX1800mesh
|
0.05/0.03
|
304 or 316
|
|
325meshX2300mesh
|
0.030/0.025
|
316L
|
|
400meshX2800mesh
|
0.030/0.02
|
316L
|
The wires of the weft and the warp intercross two above with a larger weft wire than the warp.
Such kind of wire mesh allows a greater difference between the diameter and the number of weft and warp wire.
Such kind of wire mesh allows a greater difference between the diameter and the number of weft and warp wire.
