Tab Top Type 7mm Metal Ring Mesh Curtain Stainless Steel 316L
TAB-TOP Type 7mm Metal Ring Mesh Curtain Stainless Steel 316L
Quick Details Of Metal Ring Mesh Curtain :
Metal rings mesh is an innovative and multi-purpose material for building facades and interior
decoration.7mm ring mesh as a welded type ,wildly used for decoration ,they constantly find
new applications and are inspiration for decorators and artists. They are mainly used as
curtains, separators, buildings facades, but also for the creation of furniture, lighting, etc.
| Product name | TAB-TOP type 7mm metal ring mesh curtain |
| Material | Stainless steel 316L |
| Color | gold color or Metallic primary |
| Size | 0.8x7mm |
| Type | Weld type |
| Surface treatment | polish orelectroplating |
| Application | 1.Internal and external decoration. 2.Divider or background decoration. 3.Helmets decoration. 4.Facades. 5.Exhibition design. 6.Staircase walls. 7.Mechanical filtration. 8.Fireplace screens. 9.Partition curtain wall. |
 |
|
Specification of metal ring mesh curtain
| Term | Type | Material | Wire diameter | Outer diameter | Weight/m2 |
| HH-SS-053 | Weld | stainless steel | 0.53mm | 3.81mm | 3.2kgs |
| HH-SS-080 | Weld | stainless steel | 0.80mm | 7.00mm | 2.8kgs |
| HH-SS-150 | Weld | stainless steel | 1.50mm | 15.00mm | 4.8kgs |
| HH-CS-150 | Weld | Copper/brass | 1.50mm | 15.00mm | 5.5kgs |
| HH-SS-200 | Weld | stainless steel | 2.0mm | 20.00mm | 6.8kgs |
| HH-CS-200 | Weld | Copper/brass | 2.0mm | 20.00mm | 7.8kgs |
| HH-SS-100 | Non-welding | Stainless steel | 1.0mm | 8.00mm | 4.7kgs |
| HH-MS-100 | Non-welding | Mild steel | 1.0mm | 8.00mm | 4.6kgs |
| HH-SS-120 | Non-welding | Stainless steel | 1.2mm | 10mm | 4.8kgs |
| HH-CS-120 | Non-welding | Mild steel | 1.2mm | 10mm | 5.5kgs |
| HH-SS-150 | Non-welding | Stainless steel | 1.5mm | 15mm | 4.8kgs |
| HH-CO-150 | Non-welding | Mild steel | 1.5mm | 15mm | 5.5kgs |
| HH-SS-200 | Non-welding | Stainless steel | 2.0mm | 20mm | 6.8kgs |
| HH-CO-200 | Non-welding | Mild steel | 2.0mm | 20mm | 7.8kgs |
Types of metal ring mesh curtain
 |
7mm metal ring mesh on trackMaterial :stainless steel 316L Ring size :0.8x7mm ,0.53x3.81mm colors:gold color or Metallic primary |
7mm TAB-TOP metal ring meshMaterial :stainless steel 316L Ring size :0.8x7mm,0.53x3.81mm colors:gold color or Metallic primary |
 |
 |
7mm metal ring mesh with fringingMaterial :stainless steel 316L Ring size :0.8x7mm ,0.53x3.81mm colors:gold color or Metallic primary |
Feature of metal ring mesh curtain
| Beautiful appearance | create a visually decorative effect |
| Mildew proof | also suitable for humidity environment |
| Fire prevention | metal round ring mesh is nonflammable |
| Easy maintenance | just use a piece of cloth to wipe |
| Rust resistance | no fade and good durability |
| Easy installation | lightweight and flexible structure |
| Ventilation and light transmission | keep fresh air and enhance lighting |
| Various colors and sizes | can be used in different applications |
| Unique design and style | satisfy the demand of high end customers |
Application of metal ring mesh curtain:
· A.Decorative Ring Mesh Drapery has stainless steel decorative mesh and aluminum alloy,
copper wire spiral curtain, steel plate aluminum mesh plate decorative mesh, metal bead
curtain, rope decorative net, stencil decorative net and so on.
· B.Unique fashionable metal ring mesh drapery has the characteristics of solemnity, generosity
and good three-dimensional effect. It is more attractive under the illumination of the light. It is an
ideal decorative material for modern hotels, restaurants and exhibition halls.
· C.Stainless Steel Metal ring mesh window drapery is a combination of a plurality of aluminum
mesh sheets. The main shapes of the mesh are flat, round beads, plum and diamond. Widely
used in hotels,cafes, concert halls, hotels, window decoration and other screen cut ceilings, etc.
HUIHAO Company Advantages:
1.pattern design support according to the application
2.frame design support according to the installation
3.surface treatment support ,inclode to the installation
4.supply install accessories ,include PVDF,PVD Spraying
5.Material:stainless steel ,copper ,bronze ,brass ,aluminum ,aluminum alloy ,ect
6.Weave type :Plain weave,twill weave ,dutch weave ,plain dutch weave ,twill weave ,
uinque woven method,ect
7.ISO9001-2008 Quality certification management system
