Weave Type Stainless Steel Architectural Metal Screen As Railing Infill Panels

wire mesh pattern works well as railing infill panels, facades, along with many other interior design elements. Robust on the loom,

this mesh can be woven in all wire alloys as well as mixed alloy configurations.

Architectural Metal Screen Specification:

	Material ss Opening Area 49% Warp Dia 1.6mm Mesh Th 4.2mm Warp Pitch 4.5mm Surface PVD, PVDF Weft Dia 1X3.8mm Max Width 3m Weft pitch 50mm Max Length 30m Weight 5.5kgs/m2 Application for partition
	Material Ss Opening Area 0% Warp Dia 2mm Mesh Th 4mm Warp Pitch 5mm Surface Antique brass Weft Dia 1mm×4mm Max Lengh 3000mm Weft Pitch 4mm Max Width 1500mm Weight 8.5kgs/m2 Application Interior /exterior
	Material stainless steel Opening Area 17.4% Flat Dia 1.5x7mm Mesh Th 3.5mm Flat Pitch 12mm Surface pvd,pvdf Flat Nos 1 Max Width 3m Application Interior / Exterior Max Length 6m
	Material Aluminum alloy  Opening Area 0% Warp Dia 7mmx1mm Mesh Th 3.5mm Warp Pitch 21mm Surface free oil Weft Dia 7mmx1mm Max Width 3m weft Pitch 7.0mm Max Length 6m Weight 7kgs/m2 Application Interior / Exterior
	Material SS & Co Opening Area 61% Warp Dia 2mm Mesh Th 3.3mm Warp Pitch 21.5mm Surface polish Weft Dia 2mm Max Length 30m Weft Pitch 50mm Max Width 3m Weight 4.3kgs/m2 Application cladding
	Material SS&Co Opening Area 32% Warp Dia 2mm*2 Mesh Th 6mm Warp Pitch 10mm Color customized Weft Dia 2mm*3 Application facade Weft Pitch 10mm finished clean &free Weight 14kgs/m2 Certification ISO9001

Architectural Metal Screen technical support

1.pattern design support according to the application
2. frame design support according to the installation
3. surface treatments support , include PVDF, PVD, Spraying.
4. supply install accessories, include screw, wall anchor, track, bolt and others
5.Material: stainless steel, copper, bronze, brass, aluminum, aluminum alloy, etc.
6.Weave type: plain weave, twill weave, dutch weave, plain dutch weave, twill dutch weave, unique woven method, etc.
